The events played on a MIDI keyboard are then transmitted by your Sonar to the Moog Modular V. It
is of course possible to record these MIDI events, and use all of the Sonar MIDI editing possibilities.
8.4.4

Saving presets

When the session is recorded, the state of the Moog Modular V is recorded as is, even if the pro-
gramming does not correspond to any preset. For example, if you were working on preset "P1" on
which you had modified the parameters (without having saved them under the name "P2"), the next
time the song is opened, the Moog Modular V will load preset "P1" with the modifications.
8.4.5

Automation

Automation with Sonar functions simply by the reception and recording of Control Change type MIDI
messages. You can configure the Moog Modular V MIDI message reception just as you do in stand-
alone mode. The sequencer takes care of recording the continuous control transmitted to the Moog
Modular V, and allows you to edit them.
8.5

DIGITAL PERFORMER™

8.5.1

Installation

During the initial installation, select Install as a MAS plug-in.
Then, when you are asked, indicate the folder where the other MAS plug-ins are placed. Generally
the access path is:
System Folder/Extensions/MOTU/Plug-ins
To be able to use the Moog Modular V, you need to increase the memory allocated to Digital Per-
former by around 15 Mb.
8.5.2

Opening the instrument

Access to the Moog Modular V plug-in is done like any plug-in, through the insertion of an audio
track:
152
Connecting a MIDI track to the Moog Modular V
