PLEASE LEAVE THIS MANUAL WITH THE OSO UNIT AFTER INSTALLATION
This cylinder is manufactured and approved in accordance with EN 12897 : 2006
OSO Super S front view
Thank-you for purchasing the OSO Super S unvented hot water cylinder.
Designed to be simple and neat to install, the Super S differs from other unvented cylinders in that all of the
principle connections, including hot and cold water pipes, expansion vessel and primary heating pipes on indirect
units are connected to the top of the cylinder. Full size template is provided to facilitate pipe positioning.
OSO advise that the connecting pipes and electrical cables are fixed in place prior to the positioning of the cylinder. Moving
the cylinder into position should be the last thing done before connection of pipes and commissioning of the cylinder.
This manual gives detailed advice for installation and should be read carefully prior to fitting any unvented unit. Where
components are supplied only for indirect units, this is clearly shown. OSO Super S cylinders are not suitable for gravity
fed primary systems. In known hard water regions, precautions should be taken to prevent limescale formation in hot water
cylinders, in accordance with Building Regulation Part L, Domestic Heating Compliance Guide.
This OSO cylinder must be installed by a competent person and be installed in compliance with the OSO Installation and
Maintenance Instructions, all current legislation, codes of practice and regulations governing the installation of unvented hot
water cylinders in force at the date of installation.
PLEASE READ THIS MANUAL BEFORE INSTALLATION AND LEAVE UNDER THE CYLINDER TOP LID. THE
MANUAL AND ATTACHED LOGBOOK SERVE AS THE CYLINDER GUARANTEE.
OSO Hotwater UK Ltd.
Installation Manual
For Super SX120IQ and SC120
www.osohotwater.co.uk
Super S
Contents
1. General information ........................... 2
2. Cylinder Specification ...................... 3
3. Preparation of installation area .......... 3
4. Connection of Pipework ..................... 4
5. Commissioning and filling up.............. 5
6. Electrical connection .......................... 5
7. Safety and Servicing ........................ . 14
8. Fault finding..................................... ..15
9.Technical and Performance specs ... . 16
10. Benchmark Logbook........................ . 17
Top view
Page no.
Super S
