The Back Panel

AC POWER ENTRY MODULE
The HPDA15-RM-B is configured to operate on 110 to 120 VAC.
SMA INPUTS
There are 3 amplifier modules each having one input and 5 outputs. The signal
to be distributed should be connected to the SMA jack labeled input.
SMA OUTPUTS
The 5 outputs of each amplifier module are DC isolated from the chassis ground
to prevent ground loops. Make sure that the amplifier ground does not float to a
potential greater than 50 VDC from the chassis ground.
potential greater than 50 VDC will damage the amplifier and could cause injury or
death to personnel.
Copyright © SpectraDynamics, Inc. 1999
SDI
An output ground
