Keyestudio ESP32 Robot Arm
8-6 Servo Configuration
Function: set servo at pin IO17 to the angle of 90°
http://www.keyestudio.com
*/
#include <ESP32Servo.h>
// create a servo objects Customizable name
Servo servo;
int
servoPin = 17; //Connect servo to pin IO17
void
setup()
{
servo.attach(servoPin);
servo.write(0); //Set servo angle to 0°
delay(1000);
servo.write(180);
delay(1000);
servo.write(90);
}
void
loop() {
}
After uploading the code, the servo will initialize to 0° first. Then it rotates from 0 to 180° and then it maintains at 90°.
We need to ensure the servo is at 90° position before installing.
Vertically mount it as follows:
62
//Set servo angle to 180°
//Set servo angle to 90°
Chapter 8. 8. Assembly
