keyestudio WiKi
Arm wiring:
116
Servo drive board
Left joystick module
5V(red)
V
GND(black)
G
IO12(yellow)
B
IO13(yellow)
X
IO15(yellow)
Y
Servo drive board
Right joystick module
5V(red)
V
GND(black)
G
IO25(yellow)
B
IO33(yellow)
X
IO32(yellow)
Y
