9.1.6 9.1.6 Test Result

After uploading the code, the servo rotates from 0° to 90° and delays for 1s, and then rotates to 180° and also delays
for 1s. At last, it back to 0° to repeat these actions.

9.1.7 9.1.7 Extension

We have learned how to set the servo to a certain angle without pause.
In this extension experiment, we program to control the servo to slowly rotate from 0° to 180° and then slowly back to
0° degree by degree.
9.1.7.1 Code
Download codes: Codes
Download and unzip the file. Open the corresponding code file. Code file for Chapter 9.1.7.1 is named 9-1-7-1.
/*
Keyestudio ESP32 Robot Arm
9-1-7-1 tutorial code
Function: servo slowly rotates from 0° to 180°, and then slowly back to 0°
http://www.keyestudio.com
*/
#include <ESP32Servo.h>
// create a servo objects Customizable name
Servo servo;
int
servoPin = 16; //Connect the servo to pin IO16
int
pos = 0; // position in degrees
void
setup()
{
servo.attach(servoPin);
}
void loop() {
for (pos = 0; pos
9.1. 9.1 Control Servo
<= 180; pos += 1) { // sweep from 0 degrees to 180 degrees
keyestudio WiKi
(continues on next page)
