Dacor ECD/ECS Planning Manual
Dacor ECD/ECS Planning Manual

Dacor ECD/ECS Planning Manual

27”, 30” wide, double, classic wall ovens

Advertisement

Quick Links

ECD/ECs, mCD/mCs, & PCD/PCs
091605
1" (25mm) Min.
Models
"A" Cutout Height
27"
49 1/16" (1246mm)
30"
NOTES:
1.
24" (610mm) minimum interior cabinet depth.
Back of cabinet may need to be removed.
2.
3/4" (19mm) support platform (flush with cutout).
3.
1/8" (3mm) minimum clearance to adjacent cabinet
doors/drawers.
Web: http://www.Dacor.com
Corporate Phone: 800-793-0093
27", 30" wide, Double,
Classic wall ovens
1
3
1" (25mm)
Clear to Top
of Drawer for
2
Heat Exhaust
"B" Cutout Width
25 1/2" (648mm)
28 1/2" (724mm)
"C"
"B"
"A"
CUToUT DImENsIoNs
"C" Min. Cabinet Width
27" (686mm)
30" (762mm)
Specifications are subject to change without notice.
See installation instructions for additional details.
PLANNING
GUIDE
1/2
Alternate
Electrical
Location
Recommended
Electrical
Location
3
Oven Overlays
3/4" (19mm) Each Side; 15/16" (24mm) Top;
1/16" (1mm) Bottom
1.3
