- Page 1 INSTRUCTIONS FOR USE Pro-Ject T2...
- Page 2 Dear Music Lover, Congratulations and thank you for choosing Pro-Ject Audio Systems record player. Your T2 turntable has been handcrafted and rigorously tested by skilled technicians to give you years of enjoyable, trouble-free service. If you require additional assistance, please contact your dealer.
- Page 3 Accessories SINGLE ADAPTOR ALLEN KEY 1,5mm COUNTERWEIGHT no. 105 (FOR CARTRIDGE WEIGHT 5 – 11.5g) TWO-POINT CARTRIDGE ALIGNMENT PROTRACTOR CONNECTION CABLE (CONNECT IT E RCA) SETUP GUIDE UNIVERSAL POWER SUPPLY © Pro-Ject Audio Systems · Pro-Ject T2 · Revision 22.05.2024...
- Page 4 © Pro-Ject Audio Systems · Pro-Ject T2 · Revision 22.05.2024...
- Page 5 Blue left channel L- For correct cartridge alignment, use the two-point cartridge alignment protractor provided with your T2 accessories. If unfamiliar with two-point setup, please refer to your dealer. A damaged or worn stylus may harm your record collection and should be replaced.
- Page 6 3. Vertical Tracking Force setting (VTF) The T2 Super Phono comes with the counterweight already assembled on the tonearm, and the tracking force is factory pre-adjusted. To adjust or fine tune the tracking force manually, loosen the hexagonal screw on top of the counterweight (7) using the allen key provided.
- Page 7 For detailed product information regarding Pro-Ject Audio interconnect cables and phono amplifiers, please refer to the Pro-Ject website at www.project-audio.com. The recommended load impedance for the factory fitted cartridge is: 47kohms /MM-input © Pro-Ject Audio Systems · Pro-Ject T2 · Revision 22.05.2024...
- Page 8 15-25.000Hz Channel separation 25dB/1kHz Output voltage Recommended load impedance 47kohms/ amplifier connection – MM-input Compliance/stylus type 10×10-6cm/dyn @ 100Hz– elliptical Recommended tracking force 20mN Capacitance 100pF – 200pF Weight 6.5g © Pro-Ject Audio Systems · Pro-Ject T2 · Revision 22.05.2024...
- Page 9 This guide was produced by: Pro-Ject Audio Systems notice as deemed necessary to uphold the ongoing Copyright © 2024. All rights reserved. process of technical development. © Pro-Ject Audio Systems · Pro-Ject T2 · Revision 22.05.2024...
- Page 10 EMC: EN301489-1 V2.2.0: 2017-03, EN301489-17 V3.2.0:2017-03, EN55032:2015, EN55035:2017, EN61000-3-2:2014, EN61000-3-3:2013 Radio Spectrum: EN300328 V2.1.1 (2016-11) Pro-Ject Audio Systems a division of Audio Tuning GmbH 1050 Vienna, Austria, Margaretenstrasse 98 info@project-audio.com © Pro-Ject Audio Systems · Pro-Ject T2 · Revision 22.05.2024...
- Page 11 © Pro-Ject Audio Systems · Pro-Ject T2 · Revision 22.05.2024...
- Page 12 T2 | Setup Guide Getting started: • Make sure to have enough space to unpack your turntable. • Always unpack and set up in a clean environment. • Please Do NOT throw away the packaging! If you need service or want to return your product, please send it in the original packaging including all inserts.
- Page 13 Should you encounter a problem which you are not able to alleviate or identify despite the above information, please contact your dealer for A Pro-Ject Audio Systems warranty relates to claims of defects in materials and/or workmanship at the time of purchase. It does not cover: further advice.
- Page 14 Power consumption: 4,5 W / 0 W in Stand-By • Available in high gloss Black, satin White and Walnut Dimensions: 542 x 300 x 412mm (WxHxD) • Handmade in Europe Weight: 5,5 kg net PRO-JECT AUDIO SYSTEMS Technical data and price changes reserved. www.project-audio.com Page 1/3...
- Page 15 Furthermore, the glass platter in the T2 has been made heavier and thicker compared to its predecessor, ensuring a zero-resonan- ce design that effectively eliminates the shortcomings associated with plastic or lightweight steel alternatives.
- Page 16 Sumiko Rainier MM cartridge Semi-balanced phono cable The T2 comes preadjusted with a high-value Sumiko Like the T1, the T2 is then finished with super shielded, Rainier MM cartridge (MSRP 175€) featuring an ellipti- semi-symmetrical, low-capacitance phono cables, cal diamond stylus tip; this is a true hi-fi playback sys- purpose-designed by Pro-Ject –...
- Page 17 Turntable input turned on is selected Turntable is not spinning The hum of your turntable has mechanical origins. The hum of your turntable has electrical origins: Please follow the steps on the following pages. PRO-JECT AUDIO SYSTEMS Page 1/9 www.project-audio.com...
- Page 18 Ground RCA input connection pin Ground connection pin Ground wire Ground lead/wire (turntable end) (amplifier end) Turntable connection panel (with fixed cable) Left Channel RCA wire Right Channel RCA wire Ground wire (turntable end) PRO-JECT AUDIO SYSTEMS Page 2/9 www.project-audio.com...
- Page 19 * Please note that a grounded plug is just a hint for a grounded device and a good starting point. However, this is not an absolute evidence, since the ground pin of a grounded plug does not necessarily has to be connected with the device. Grounded Power Cable: Pro-Ject Connect it Power PRO-JECT AUDIO SYSTEMS Page 3/9 www.project-audio.com...
- Page 20 * Please note that a grounded plug is just a hint for a grounded device and a good starting point. However, this is not an absolute evidence, since the ground pin of a grounded plug does not necessarily has to be connected with the device. PRO-JECT AUDIO SYSTEMS Page 4/9...
- Page 21 Pro-Ject High Power it Possible setup (floating ground): Amplifier Phono preamp Turntable Pro-Ject High Power it power supply will ground your system and can help to elimi- nate hum Pro-Ject High Power it power supply PRO-JECT AUDIO SYSTEMS Page 5/9 www.project-audio.com...
- Page 22 The Amplifier has a grounded connection and there is one single, proper ground for the entire setup. Turntable and Phono preamp ground are connec- ted to the Amplifier ground via the ground wire of the RCA cables. PRO-JECT AUDIO SYSTEMS Page 6/9 www.project-audio.com...
- Page 23 They feature a big set of options to individually tailor the preamp to the MC cartridge, resulting in best audio performance without noise. See chapter 4. for more information. Tube Box S2 Phono Box S2 Ultra PRO-JECT AUDIO SYSTEMS Page 7/9 www.project-audio.com...
- Page 24 Not Usable for low output MC Phono Box Fixed Gain/Impedance/Capacity settings with simple switch between MM and MC OK for MC Phono Box S2 Ultra Variable Gain/Impedance/Capacity settings Best solution for MC and MM PRO-JECT AUDIO SYSTEMS Page 8/9 www.project-audio.com...
- Page 25 & prone to interference. Try to seperate them & cross them - when necessary - as close to 90° as possible. Avoid Audio cable Power cable Audio cable Power cable PRO-JECT AUDIO SYSTEMS Page 9/9 www.project-audio.com...
