Assa Abloy Sargent PE8600 Series Installation Instructions Manual

Concealed vertical rod exit devices

Advertisement

Quick Links

Installation Instructions
PE8600 Series (12-WD, WD, NB-12-WD, & NB-WD)
Concealed Vertical Rod Exit Devices
WARNING
This product can expose you to
lead which is known to the state of
California to cause cancer and birth
defects or other reproductive harm.
For more information go to www.
P65warnings.ca.gov.
1-800-727-5477 • www.sargentlock.com
Copyright © 2023, SARGENT Manufacturing Company. All rights reserved. Reproduction in whole or in part without the express written
permission of SARGENT Manufacturing Company is prohibited. Patent pending and/or patent www.assaabloydss.com/patents.
WARNING
Attention Installer: Improper
installation may result in damage
to the product and void the factory
warranty.
A8315-1 5/23

Advertisement

loading

Summary of Contents for Assa Abloy Sargent PE8600 Series

  • Page 1 Installation Instructions PE8600 Series (12-WD, WD, NB-12-WD, & NB-WD) Concealed Vertical Rod Exit Devices WARNING WARNING This product can expose you to Attention Installer: Improper lead which is known to the state of installation may result in damage California to cause cancer and birth to the product and void the factory defects or other reproductive harm.
  • Page 2: Screw Chart

    PE8600 Series (12-WD, WD, NB-12-WD & NB-WD) Concealed Vertical Rod Exit Devices Installation Instructions Screw Chart TOTAL QTY DESCRIPTION WHERE USED SUPPLIED (4) CHASSIS CORNER MOUNTING HOLES (2) INNER CHASSIS PLATE (2) 650 STRIKE, TOP (WOOD FRAME) #10 X 1-1/4" FLAT HEAD (2) 650 STRIKE, BOTTOM WOOD SCREW (WOOD FRAME)
  • Page 3: Equipment Needed

    PE8600 Series (12-WD, WD, NB-12-WD & NB-WD) Concealed Vertical Rod Exit Devices Installation Instructions Equipment Needed Tools Support Block (Provided) Rail Cutting Guide (Provided) Strike Packs 650 Top Strike Pack NB-WD-PE8600 Strike Pack for Strike Pack for 12-WD-PE8600 & 12-NB-WD-PE8600 WD-PE8600 *Note: The NB-WD-PE8600, 12-NB-WD-PE8600 do not have a bottom strike.
  • Page 4 PE8600 Series (12-WD, WD, NB-12-WD & NB-WD) Concealed Vertical Rod Exit Devices Installation Instructions Template for WD-PE8600, 12-WD-PE8600, NB-WD-PE8600 and NB-12-WD-PE8600 with P700 Series Trim P700 SERIES TRIM 39-5/8” The P700-4 series trim needs to be attached through the door with (2) 1/4-20 x 2-3/8” flat head machine screws (GG).
  • Page 5: Exploded View

    PE8600 Series (12-WD, WD, NB-12-WD & NB-WD) Concealed Vertical Rod Exit Devices Installation Instructions Exploded View Top Chassis THIS EXIT DEVICE IS HANDED CHECK HAND OF DEVICE AGAINST APPLICATION Top rod assembly OUTSIDE RIGHT HAND LEFT HAND REVERSE REVERSE BEVEL BEVEL INSIDE Rod silencer...
  • Page 6 PE8600 Series (12-WD, WD, NB-12-WD & NB-WD) Concealed Vertical Rod Exit Devices Installation Instructions Install inner chassis into door prep. Note: Wood doors must be prepared by a wood door manufacturer. A8315-1 5/23 1-800-727-5477 • www.sargentlock.com Copyright © 2023, SARGENT Manufacturing Company. All rights reserved. Reproduction in whole or in part without the express written permission of SARGENT Manufacturing Company is prohibited.
  • Page 7 PE8600 Series (12-WD, WD, NB-12-WD & NB-WD) Concealed Vertical Rod Exit Devices Installation Instructions Mark inner chassis mounting holes. Remove the inner chassis. Pilot drill inner chassis mounting holes for #10 wood screws. A8315-1 5/23 1-800-727-5477 • www.sargentlock.com Copyright © 2023, SARGENT Manufacturing Company. All rights reserved. Reproduction in whole or in part without the express written permission of SARGENT Manufacturing Company is prohibited.
  • Page 8 PE8600 Series (12-WD, WD, NB-12-WD & NB-WD) Concealed Vertical Rod Exit Devices Installation Instructions Install the inner chassis using two (2) #10 x 1-1/4” screws (CC). Install #10-24 x 3/8” fillister screws (HH) to the inner chassis. A8315-1 5/23 1-800-727-5477 • www.sargentlock.com Copyright ©...
  • Page 9 PE8600 Series (12-WD, WD, NB-12-WD & NB-WD) Concealed Vertical Rod Exit Devices Installation Instructions • Slide top rod into the door and thread into the inner chassis. • Ensure the teeth on the top bolt are facing opposite of the inside face of the door.
  • Page 10 PE8600 Series (12-WD, WD, NB-12-WD & NB-WD) Concealed Vertical Rod Exit Devices Installation Instructions • Locate the center chassis on the door by keying it to the fillister head screw projecting off the door face. • Mark the four corner mounting holes. A8315-1 5/23 1-800-727-5477 •...
  • Page 11 PE8600 Series (12-WD, WD, NB-12-WD & NB-WD) Concealed Vertical Rod Exit Devices Installation Instructions Remove the center chassis from the door. Pilot mounting holes for a #10 wood screw. Install the center chassis using four (4) #10 x 1-1/4” screws (CC).
  • Page 12 PE8600 Series (12-WD, WD, NB-12-WD & NB-WD) Concealed Vertical Rod Exit Devices Installation Instructions Adjusting the top bolt and rod assembly • 1/8” gap or less between door top and frame: Rotate bolt to make it even with the top of the door. •...
  • Page 13 PE8600 Series (12-WD, WD, NB-12-WD & NB-WD) Concealed Vertical Rod Exit Devices Installation Instructions • Slide the top case over the top bolt. • Slide the bottom plate over the bottom bolt. Mark the top case and bottom plate mount locations. A8315-1 5/23 1-800-727-5477 •...
  • Page 14 PE8600 Series (12-WD, WD, NB-12-WD & NB-WD) Concealed Vertical Rod Exit Devices Installation Instructions • Remove the top case and bottom plate. • Pilot drill the top case holes for #12 wood screws. • Pilot drill the bottom plate holes for 1/4” wood screws •...
  • Page 15 PE8600 Series (12-WD, WD, NB-12-WD & NB-WD) Concealed Vertical Rod Exit Devices Installation Instructions • Attach 650 strike to frame with (2) #10-24 x 1/2” flat head screws. A8315-1 5/23 1-800-727-5477 • www.sargentlock.com Copyright © 2023, SARGENT Manufacturing Company. All rights reserved. Reproduction in whole or in part without the express written permission of SARGENT Manufacturing Company is prohibited.
  • Page 16 PE8600 Series (12-WD, WD, NB-12-WD & NB-WD) Concealed Vertical Rod Exit Devices Installation Instructions • For WD-PE8600: Attach 650 bottom strike to Reinstall the door into the frame. floor with anchors and supplied fasteners. • For 12-WD-PE8600 attach 606 bottom strike to floor with anchors and supplied fasteners.
  • Page 17 PE8600 Series (12-WD, WD, NB-12-WD & NB-WD) Concealed Vertical Rod Exit Devices Installation Instructions Rail cutting guide If the rail doesn’t need to be cut, continue to page 18 step 19. If the rail must be cut, follow these steps on page 16 and 17: Refer to the individual exit device installation instructions for rail cutting requirements / restrictions.
  • Page 18 PE8600 Series (12-WD, WD, NB-12-WD & NB-WD) Concealed Vertical Rod Exit Devices Installation Instructions Rail cutting guide, continued. Cut line C. Ensure plastic insert support is installed under D. Wrap the rail and insert in masking tape, the cut line. as shown.
  • Page 19 PE8600 Series (12-WD, WD, NB-12-WD & NB-WD) Concealed Vertical Rod Exit Devices Installation Instructions Slide the rail assembly on the chassis. Ensure rail carrier tabs are aligned with chassis. Tighten chassis mounting screws. Ensure mounting rail bracket is against Insert the mounting bracket in the end of the the rail without a gap.
  • Page 20 PE8600 Series (12-WD, WD, NB-12-WD & NB-WD) Concealed Vertical Rod Exit Devices Installation Instructions Pilot mounting bracket holes for #10 wood Level the rail and mark mounting holes, using the screws. bracket as a guide. Atttach mounting bracket with (2) #10 wood screws (BB).
  • Page 21 PE8600 Series (12-WD, WD, NB-12-WD & NB-WD) Concealed Vertical Rod Exit Devices Installation Instructions TOP BOLT ADJUSTMENT BOTTOM BOLT ADJUSTMENT If adjustments are needed, before closing the door check the following: • Push rail in to retract bolts. • Bolts stay retracted (hold back). •...
  • Page 22 PE8600 Series (12-WD, WD, NB-12-WD & NB-WD) Concealed Vertical Rod Exit Devices Installation Instructions Check for proper operation. Install chassis and end cap cover, using supplied #8-32 x 5/16 oval head screws (FF). A8315-1 5/23 1-800-727-5477 • www.sargentlock.com Copyright © 2023, SARGENT Manufacturing Company. All rights reserved. Reproduction in whole or in part without the express written permission of SARGENT Manufacturing Company is prohibited.
  • Page 23 PE8600 Series (12-WD, WD, NB-12-WD & NB-WD) Concealed Vertical Rod Exit Devices Installation Instructions A8315-1 5/23 1-800-727-5477 • www.sargentlock.com Copyright © 2023, SARGENT Manufacturing Company. All rights reserved. Reproduction in whole or in part without the express written permission of SARGENT Manufacturing Company is prohibited. Patent pending and/or patent www.assaabloydss.com/patents.
  • Page 24 1-800-727-5477 • www.sargentlock.com Copyright © 2023, SARGENT Manufacturing Company. All rights reserved. Reproduction in whole or in part without the express written A8315-1 5/23 permission of SARGENT Manufacturing Company is prohibited. Patent pending and/or patent www.assaabloydss.com/patents.
