Wear ear-muffs.
The impact of noise can cause damage to hearing.
Keep the noise emissions and vibrations to a mini-
mum.
• Only use appliances which are in perfect working
order.
• Service and clean the appliance regularly.
• Adapt your working style to suit the appliance.
• Do not overload the appliance.
• Have the appliance serviced whenever necessary.
• Switch the appliance off when it is not in use.
• Wear protective gloves.

7. Unpacking

• Open the packaging and remove the device care-
fully.
• Remove the packaging material as well as the
packaging and transport bracing (if available).
• Check that the delivery is complete.
• Check the device and accessory parts for trans-
port damage.
• If possible, store the packaging until the warranty
period has expired.
ATTENTION
The device and packaging materials are not toys!
Children must not be allowed to play with plas-
tic bags, film and small parts! There is a risk of
swallowing and suffocation!

8. Before commissioning

Check the device, all tools and accessory parts for
visible damage before use. Damaged tools shall not
be used.
An adequately powerful compressed air source (e.g.
compressor) of 3 to 6.3 bar and a suction perfor-
mance of at least 160 l/min is required for the air
supply for the compressed air device.
m Attention! Danger of device damage if the
operating pressure at the device is more than
6.3 bar.
The following compressors are recommended:
24 litres Light work
50 litres Moderate work
100 litres and more Heavy work
Connection
• We recommend connecting a maintenance unit
with a mist lubricator between the compressed air
source and the compressed air tool (not includ-
ed in the scope of delivery). Alternatively, add 3-5
drops of oil into the compressed air connection
each time before starting the compressed air tool.
• The compressed air hose (not included in the de-
livery) should not be longer than 15 metres and
should have an internal diameter of at least 8 mm
in order to minimise pressure loss.
m Attention! Danger of tripping due to improp-
erly laid compressed air hoses! Lay the com-
pressed air hoses such that they do not cross
paths and such that they are flat to the floor.
Always lay the compressed air hoses such that
there is a reasonable amount of spare hose
length in the work area.
• Note that the line oiler should be attached at the
same floor level or storey as the working device.
Lubrication
• If the insertion end (hex.) of the tool being used is
lightly moistened with oil after operation, the oiler
is correctly set.
• If oil emerges at the valve on the actuation body or
if it runs along the tool attachment, the oil quantity
is set too high.
• Adjust oil quantity and top up oil
• Please use special compressed air oil - important:
Use only resin-free oil!

9. Inserting/replacing tool

m Risk of injury due to tools! To insert or replace
tools, the device must be rendered pressure-less
as a matter of principle as otherwise the device
could be unintentionally started up if handled
incorrectly. When dealing with sharp, pointed or
hot tools, always wear suitable protective gloves
in order to avoid injuries.
Use only original tools or tools that have been ex-
pressly approved by the manufacturer for use with
this compressed air device.
Inserting tool (fig. 2)
1. Hold the compressed air device with the tool re-
ceiver (1) upwards. Support the other end on the
ground. If the compressed air device has already
been in operation, check whether the tool receiv-
er (1) is oily.
2. Insert the tool (7) into the tool receiver (1) with
the hex. in the required orientation.
3. Slide the sliding sleeve (2) downwards with the
other hand until the tool (7) slides into the re-
ceiver. Guide the sliding sleeve back into place
again (2).
4. Pull the tool (7) to check that it is correctly latched
into the tool receiver (1). Check whether the hex.
of the tool (7) is positively locked into the tool
receiver.
5. Slide the sliding sleeve (2) halfway downwards.
6. Pull the tool (7) out with the other hand. Guide the
sliding sleeve back into place again (2).
