VHD-VFD/DN & VHD-VRD/DN
INSTALATION MANUAL
.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the VHD-VFD/DN and is the answer not in the manual?

Questions and answers

Summary of Contents for Vista VHD-VFD/DN

  • Page 1 VHD-VFD/DN & VHD-VRD/DN INSTALATION MANUAL...
  • Page 2 INFORMATION FOR USER CAUTION RISK OF ELECTRIC SHOCK DO NOT OPEN CAUTION : TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE COVER (OR BACK). NO USER SERVICEABLE PARTS INSIDE. REFER SERVICING TO QUALIFIED SERVICE PERSONNEL. The lightning flash with arrowhead symbol, within an equilateral triangle is intended to alert the user to the presence of uninsulated "dangerous voltage"...
  • Page 3: Table Of Contents

    CONTENTS Precautions Features Model selection Part names 3-Axis Camera Setting Installation Accessories and others Connection Dimensions Main Menu Exposure White Balance Image Intelligent Special Function Display Specifications Troubleshooting...
  • Page 4: Precautions

    PRECAUTIONS Do not install the camera in extreme temperature conditions. Do use the camera unless the temperature is within -10°C to 50 C. Be especially careful to include ventilation in high temperatures. Do not install or use the camera in an environment where the humidity is high.
  • Page 5: Features

    FEATURES VANDAL DOME HOUSING This colour video camera is designed for use in security systems. · IP67 Rating, Aluminum Die-casting Rugged Vandal proof Camera · Wall or Ceiling Mounting through 3-Axis camera bracket · 1/3" Panasonic CMOS sensor · Full HD Resolution ·...
  • Page 6 FEATURES PLASTIC DOME HOUSING This colour video camera is designed for use in security systems. · Wall or Ceiling Mounting through 3-Axis camera bracket · Safety strap holds dome cover in place while making adjustments · 1/3" Panasonic CMOS sensor ·...
  • Page 7: Model Selection

    MODEL SELECTION 3PCS VANDAL HOUSING Normal type PLASTIC HOUSING Normal type...
  • Page 8: Part Names

    PART NAMES 3PCS VANDAL HOUSING Focus/Zoom Lever Lock Screw Camera Bracket NORMAL TYPE PLASTIC HOUSING Focus/Zoom Lever Lock Screw Camera Bracket NORMAL TYPE...
  • Page 9: 3-Axis

    3-AXIS Set Camera DIRECTION (3-axis movement) Ceiling Type Wall Type PAN SWIVEL 360° TILT SWIVEL 360° BRACKET 80° PCB BRACKET 80° PAN SWIVEL 360° TILT SWIVEL 360° hold the 4 points and swivel it. PCB BRACKET 90° PCB BRACKET 80°...
  • Page 10: Camera Setting

    CAMERA SETTING Camera Setting Focus / Zoom Focus / Zoom Lever Lock Screw Lever Cover Open Menu Operation DOWN GND(GRAY) ADKEY(PINK) DC12V 12VDC CAUTION!!! CVBS (YELLOW) HDSDI (BLUE SKY) 485+(ORANGE) 485-(DARK BLUE) D/N-IN(BLUE) 485+(ORANGE) MD/OUT(PURPLE) 485-(DARK BLUE) GND(GRAY) D/N-IN(BLUE) ADKEY(PINK) MD/OUT(PURPLE) GND(GRAY) ADKEY(PINK)
  • Page 11: Installation

    INSTALLATION Plastic Dome Camera 3 pcs Vandal Dome Camera Surface Mount bracket Mount CAP Mount Screw PISE Open With Rubber Dome Base Dome Cover Machine Screw With Rubber Decoration Ring Dome cover L-Wrench 1. Dome Base Mounting - Remove the protecting sheet from the rubber bottom and attach it on the base housing. - Fix the base housing with the supplied 4pcs of screws (No.8-38 UNC) on the ceiling or wall.
  • Page 12: Accessories And Others

    ACCESSORIES AND OTHERS PLASTIC DOME TYPE DOWN Mount Screw OSD key User's Manual 3PCS VANDAL HOUSING L-wrench Mount Screw Security Tool User's Manual DOWN Mount Cap OSD key...
  • Page 13: Connection

    CONNECTION DC 12V power Input Model - Connect the video out jack to the video in jack monitor - Connect the adapter to the power input connecter - Use a DC12V and 1A adapter DC12V 12VDC CAUTION!!! CVBS (YELLOW) HDSDI (BLUE SKY) 485+(ORANGE) 485-(WHITE) D/N-IN(BLUE)
  • Page 14: Dimensions

    DIMENSIONS (MM) PLASTIC HOUSING φ100.0 φ124.1 68.5 3PCS VANDAL HOUSING 80.0 46.0 Ø143.6...
  • Page 15: Main Menu

    MAIN MENU MAIN MENU MENU MODEL D&N EXPOSURE WHITE BAL IMAGE INTELLIGENCE SPECIAL FUNC DISPLAY EXIT Functions can be set-up using the Menu Key or Pelco protocol. The menu consists of the “Main Menu” and “Sub Menus”. The main Menu displays 6 camera functions that can be selected. Sub-Menus are displayed by pressing each main menu selection MODEL Select model...
  • Page 16: Exposure

    EXPOSURE EXPOSURE MENU EXPOSURE MODEL BRIGHTNESS EXPOSURE LENS WHITE BAL SHUT SPEED AUTO IMAGE INTELLIGENCE SPECIAL FUNC WDR/BLC DISPLAY DAY&NIGHT EXIT SMART IR RETURN · BRIGHTNESS: Adjust brightness level. - 0 (dark) ~ 20 (bright) steps. · LENS - MANUAL ·...
  • Page 17 EXPOSURE · DAY&NIGHT : Select Day&Night 1. D&N Model - AUTO / DAY / NIGHT / EXT ▷ Delay : 0 ~ 255 second ▷ BURST : OFF / ON ▷ THRS : LOW / MIDDLE / HIGH Select Day&Night change level. Higher level make the night mode changed in lower illumination.
  • Page 18: White Balance

    WHITE BALANCE WHITE BALANCE MENU WHITE BAL MODEL AUTO EXPOSURE CHROMA WHITE BAL RETURN IMAGE INTELLIGENCE SPECIAL FUNC DISPLAY EXIT · AWB : Select WHITE BALANCE mode - AUTO / PRESET / MANUAL / INDOOR / OUTDOOR ▷ AUTO : Automatically adjusts color according to the lighting. ▷...
  • Page 19: Image

    IMAGE IMAGE IMAGE MENU SHARPNESS EXPOSURE MIRROR WHITE BAL FREEZE IMAGE E.ZOOM INTELLIGENCE SPECIAL FUNC DISPLAY AUTO EXIT D.COMPRESS RETURN ·SHARPNESS: Adjust sharpness level. - 0 ~ 10 steps · MIRROR: Select a flip mode. - OFF / H / V / H&V ▷H: Flips the picture horizontally on the screen.
  • Page 20: Intelligent

    INTELLIGENT INTELLIGENT MODEL PRIVACY EXPOSURE MOTION WHITE BAL RETURN IMAGE INTELLIGENCE SPECIAL FUNC DISPLAY EXIT · PRIVACY: Hide an on screen area. - OFF / ON ▷ MASK#: Select mask area number (0 ~ 31). ▷ MODE: Set-up masking areas (OFF / ON). ▷...
  • Page 21 INTELLIGENT ▷X-POS: Adjust the mask X-Axis position. ▷Y-POS: Adjust the mask Y-Axis position. ▷X-SIZ: Adjust the mask X-Axis size. ▷Y-SIZ: Adjust the mask Y-Axis size. ▷TRANS: Adjust colour tone of out of selected areas. ▷ SMART ZOOM: Adjust SMART ZOOM of MD (OFF / ON). ▷IN/OUT: Working Zoom in/out;...
  • Page 22: Special Function

    SPECIAL FUNCTION SPECIAL FUNCTION MENU SPECIAL FUNC SHADING DET EXPOSURE SHADING WHITE BAL DEFECT DET IMAGE DEFOG INTELLIGENCE SYSTEM NTSC SPECIAL FUNC HD FORMAT 1080P DISPLAY EXIT CVBS COMM DEFAULT RETURN · SHADING DET: Sets the shading calibration that the Lens will perform. Only occurs if the entire screen is viewed in white light (OFF / ON).
  • Page 23: Display

    DISPLAY DISPLAY MENU MODEL DISP SEL SET TITLE EXPOSURE RETURN WHITE BAL IMAGE INTELLIGENCE SPECIAL FUNC DISPLAY EXIT · DISP SEL : Select display item. - ID : OFF / ON - TITLE : OFF / ON - EZOOM : OFF / ON ·...
  • Page 24 VHD-VFD/DN & VHD-VRD/DN Model 1/3" Panasonic CMOS Image Sensor 2010(H) x 1108(V) = 2,227,080 (pixel) Total Pixels 1944(H) x 1092(V) = 2,122,848 (pixel) Active pixels Progressive Scanning system Digital ; 1920x1080p(1080p/30fps) , 1280x720p(720p/60fps) Resolution Analog : 700TVL Color : 1.0 lux , BW : 0.5lux Min.
  • Page 25: Specifications

    SPECIFICATIONS Model VHD-VFD/DN & VHD-VRD/DN x1 ~ x32 E.ZOOM Off / On Off / On Off / Low / Middle / High / Auto OFF / ON D.COMPRESS INTELLIGENCE Off / On (32 points) PRIVACY Off / On (4 points)
  • Page 26 SPECIFICATIONS Model VHD-VFD/DN & VHD-VRD/DN General Power Input DC JACK BNC Connector Video Output(HD-SDI) -10℃ ~ +50℃ (Humidity : 0%RH ~ 80%RH) Operating Temperature -20℃ ~ +60℃ (Humidity : 0%RH ~ 90%RH) Storage Temperature)
  • Page 27: Troubleshooting

    TROUBLESHOOTING TROUBLESHOOTING If there are problems in operation, refer to the possible solutions below. If the problem persists, please contact the distributor you purchased this product from. Possible Problems & Solutions · Nothing appears on the screen. -Check the power connections and power supply is functioning. -Check the video signal line connections.
  • Page 28 MEMO...
