Warning
2 Half -wave f ailures
3 Torch cooling warning
4 Shielding gas
5 Coolant flow
6 Wire reserve
7 CAN bus f ailure
8 Welding circuit
9 WF conf iguration
10 Partial inverter
11 Excess temperature of the coo-
lant [1]
12 Welding monitoring
13 Contact error
14 Alignment error
15 Mains f use
16 Shielding gas warning
17 Plasma gas warning
18 Forming gas warning
19 Gas warning 4
20 Coolant temperature warning
21 Excess temperature 2
22 Excess temperature 3
23 Excess temperature 4
24 Coolant flow warning
25 Flow 2
26 Flow 3
27 Flow 4
28 Wire stock warning
29 Low wire 2
30 Low wire 3
31 Low wire 4
32 Tacho error
33 Excess current on the wire feed
motor
099-5TLPXQ-EW501
15.12.2022
Potential cause / remedy
Check process parameters.
Check coolant level and top up if necessary.
Check shielding gas supply.
Check min. flow rate.
[2]
Only a small amount of wire is left on the spool.
Wire f eeder not connected; automatic circuit-breaker of wire
f eed motor (reset the tripped automatic circuit-breaker by actu-
ating).
The inductance of the welding circuit is too high for the selected
welding task.
Check WF configuration.
One of several partial inverters is not supplying welding current.
Check temperature and switching thresholds.
The actual value of a welding parameter is outside the specified
tolerance field.
The resistance in the welding circuit is too high. Check earth
connection.
Switch the machine off and on. If the error persists, notify Ser-
vice.
The power limit of the mains fuse is reached and the welding
power is reduced. Check the fuse setting.
Check the gas supply.
Check the gas supply.
Check the gas supply.
reserved
Check coolant level and top up if necessary.
reserved
reserved
reserved
Check coolant supply.
Check coolant level and top up if necessary.
Check f low and switching thresholds.
reserved
reserved
reserved
Check wire f eeding.
reserved
reserved
reserved
Fault of wire feeder - permanent overload of the wire drive.
Excess current detected on wire f eed motor.
Rectifying faults
Warnings
[2]
[2]
