Summary of Contents for Crystal Image Technologies RM-DK17
- Page 1 KVM switch and rackmount screen technology User Manual 17” 4K LCD Console Drawer RM-DK17 1U Dual Slide LCD Console Drawer Options : - SDI - HDMI - DC power UM-CV-751-DK17-Q322V1 www.rackmountsales.com...
- Page 2 Legal Information First English printing, July 2022 Information in this document has been carefully checked for accuracy; however, no guarantee is given to the correctness of the contents. The information in this document is subject to change without notice. We are not liable for any injury or loss that results from the use of this equipment.
-
Page 3: Table Of Contents
Contents RM-DK17 < Part. 1 > Package Content Structure Diagram & Dimension Installation Connection < Part. 2 > Specifi cations / OSD Product Specifi cations Keyboard / Mouse Specifi cations P.10 On-screen Display Operation ( OSD ) P.13 < Part. 3 >... - Page 4 Before Installation ■ It is very important to mount the equipment in a suitable cabinet or on a stable surface. ■ Make sure the place has a good ventilation, is out of direct sunlight, away from sources of excessive dust, dirt, heat, water, moisture and vibration. Unpacking The equipment comes with the standard parts shown in package content.
-
Page 5: Part. 1 > Rm-Dk17
< Part 1 > RM-DK17 < 1.1 > Package Content RM-DK17 unit X 1 USB cable X 2 - Power cord X 1 - M6 screw, cage nut & cup washer X 8 The above package content is only for the single console models. - Page 6 < 1.2 > Dimension Front View Rear View AC Input Keyboard Mouse 100~240V Power attached 6ft DP cable UNIT : mm Side View 1mm = 0.03937 inch Top View Product Dimension Packing Dimension Gross Model Net Weight (W x D x H) (W x D x H) Weight 441.6 x 650 x 44 mm...
-
Page 7: Installation
RM-DK17 < 1.3 > Installation - How to install Installation Slides Step ■ Insert the left and right rear mounting brackets into the LCD console drawer. Step ■ Measure the depth of the front and rear mounting rails. ■ Align each rear mounting bracket to a suitable length. - Page 8 < 1.3 > Installation - How to Use the Dual Slides ■ Press the handle button and gently slide out the drawer. ■ Flip up the LCD to a suitable angle. ■ Operate the LCD console drawer. UM-CV-751-DK17-Q322V1 www.rackmountsales.com...
- Page 9 RM-DK17 Installation - How to Use the Dual Slides ■ Flip down the front panel. ■ Press the handle button and gently push back the drawer into the rack. ■ Return the LCD console drawer to park position. UM-CV-751-DK17-Q322V1 www.rackmountsales.com...
- Page 10 < 1.4 > RM-DK17 Connection DP Server LCD Console Drawer POWER AC Input 100~240V attached 6ft K/B & MS DP cable USB cable DP server RM-DK17 Connection external KVM LCD Console Drawer LCD Console Drawer POWER AC Input 100~240V attached 6ft K/B &...
- Page 11 Intentionally Left Blank UM-CV-751-DK17-Q322V1 www.rackmountsales.com...
-
Page 12: Product Specifi Cations
< Part 2 > < 2.1 > Product Specifi cations Panel Size ( diagonal ) 17.3-inch Widescreen TFT color LCD Panel Display pixel ( dots x lines ) 3840 x 2160@60Hz Brightness ( typ. ) Contrast Ratio ( typ. ) 1000:1 Color 16.7 M, 8-bit... - Page 13 RM-DK17 Product Specifi cations Physical Product ( W x D x H ) 441.6 x 650 x 44 mm Specifi cation 17.4 x 25.6 x 1.73 inch Packing ( W x D x H ) 590 x 815 x 140 mm 23.2 x 32.1 x 5.5 inch...
-
Page 14: Keyboard / Mouse Specifi Cations
< 2.2 > Keyboard / Mouse Specifi cations tp keyboard integrated with touchpad Key force 55 ± 5g Travelling distance 3 ± 0.3mm Switch life > 10 million life cycle time OS support Windows / Linux / Unix / Mac OS Supporting layouts America United States... - Page 15 RM-DK17 MAC Keyboard / Mouse Options MAC keyboard integrated with touchpad Supporting layouts America United States How to Use "MAC" Keyboard Keyboard Features Decrease display brightness Fast-forward Increase display brightness Mute sound Mission control * Only works with OS X Lion Decrease volume default Keyboard Shortcuts.
- Page 16 < 2.2 > SUN Keyboard / Mouse Options S keyboard integrated with touchpad Ca ps Scro ll Comp ose S keyboard integrated with touchpad / trackball ■ Incorporates SUN keys, including Stop, Cut, Paste, Compose, Copy and Help ■ 104 key notepad keyboard with full numerical pad and SUN function ■...
-
Page 17: On-Screen Display Operation ( Osd )
RM-DK17 < 2.3 > On-screen Display Operation ( OSD ) Power light Green = On Orange = Power saving Membrane Switch Function Power on / off LCD Display the OSD menu Scrolls through menu options and adjusts the displayed control... - Page 18 < 2.3 > On-screen Display Operation ( OSD ) Picture Brightness : Adjust the screen brightness Contrast : Adjust the diff erence between the image background ( black level ) and the foreground ( white level ) Black level : Adjust background black level of the screen : Screen in power saving mode Position Picture size : Adjust the image size...
- Page 19 RM-DK17 On-screen Display Operation ( OSD ) Reset Reset : Return the adjustment back to factory setting PIP mode : Enter into PIP / PBP setting - PIP MODE / PBP 2WIN ( Main screen + 1 sub screen ) /...
- Page 20 < Part 3 > < 3.1 > Options : 3G / HD / SD-SDI input Crystal Image’ SDI input is an ideal solution for the broadcast- grade video and high resolution CCTV market. Designed for use with Crystal Image displays, a SDI input module can support up to 1080p @60Hz resolution without using additional space or power and it comes standard with a 2-year warranty.
-
Page 21: Hdmi
RM-DK17 < 3.2 > Options : HDMI - HDMI 2.0 ( HDCP 2.2 ) Keyboard Mouse Power attached 6ft attached 6ft HDMI cable DP cable UM-CV-751-DK17-Q322V1 P.17 www.rackmountsales.com... - Page 22 < 3.3 > Options : DC Power Model 125V 250V Input rating Input voltage: 12-Volt 24-Volt 48-Volt 110-Volt 300-Volt Input range: 9 ~ 18V 18 ~ 36V 36 ~ 75V 66 ~ 160V 180 ~ 425V Input current - No load 50 mA 50 mA 50 mA...
-
Page 23: Kvm Integration
(W x D x H) Weight 441.6 x 650 x 44 mm 590 x 815 x 140 mm 13 kg 19 kg RM-DK17 w/ KVM 17.4 x 25.6 x 1.73 inch 23.2 x 32.1 x 5.5 inch 28.6 lb 41.8 lb UM-CV-751-DK17-Q322V1 P.19... - Page 24 The company reserves the right to modify product specifi cations without prior notice and assumes no responsibility for any error which may appear in this publication. All brand names, logo and registered trademarks are properties of their respective owners. UM-CV-751-DK17-Q322V1 www.rackmountsales.com...
