Futech MULTICROSS 3D COMPACT RED User Manual page 6

ATTENTION
If the workplace is very brightly lit, e.g. out of
doors, it may be necessary to use the laser receiver.
RECEIVER MODE / BRIGHT MODE
When switch on the laser, both in self levelling as
in manual slope mode, the receiver mode (pulse)
is activated. The receiver indicator [D] will light
up. At this moment, laserlines can be picked up
by a laser receiver.
Press the Bright/Receiver mode button [A] to turn
on the bright mode.
When this mode is active, the laser lines will shine
brighter and become more visible to the eye.
A receiver can no longer be used, the receiver
indicator [D] will no longer illuminate.
· Press the Bright/Receiver button [A] again to
turn on the receiver mode (pulse) again.
NOTE
All Futech laser will use 10Khz as frequency in
receiver mode. Only receivers that can detect
laser lines at 10KHz are compatible.
6
DECLARATION OF CONFORMITY
Futech (Belgium) declares under its own responsibility that
this device:
- 035.3DR, MULTICROSS 3D COMPACT RED
- 035.3DG, MULTICROSS 3D COMPACT GREEN
- 035.4DG, MULTICROSS 4D COMPACT GREEN
is in conformity with the standards
EMC DIRECTIVE 2014/30/EU:
- EN IEC 61326-1: 2021
- EN IEC 61000-3-2: 2019 + A1:2021
- EN 61000-3-3:2013 + A1:2019 + A2:2021
DIRECTIVE 2011/65/EU (ROHS)
- IEC 62321-3-1:2013
- IEC 62321-5:2013
- IEC 62321-4:2013+AMD1:2017
- IEC 62321-7-1:2015
- IEC 62321-7-2:2017
ANSI C63.4-2014
- FCC 47 CFR PART 15 SUBPART B:2022
E.C.R. 2016 - UK SI 2016 No. 1091
- BS EN IEC 61326-1:2021
- BS EN IEC 61000-3-2:2019 + A1:2021
- BS EN 61000-3-3:2013 + A1:2019 + A2:2021
Lier, Belgium,
January 29, 2024
Patrick Waûters
Potential misprints are reserved. Images used are not strict. All features,
functionality and other product specifi cations are subject to change without
notice or obligation.
