Rockwell Automation Allen-Bradley ControlLogix 5570 Installation Instructions Manual

Installation Instructions
Original Instructions
ControlLogix 5570 Controllers
Catalog Numbers 1756-ESMCAP, 1756-ESMCAPK, 1756-ESMCAPXT, 1756-ESMNRM, 1756-ESMNRMK, 1756-ESMNRMXT, 1756-ESMNSE, 1756-ESMNSEK,
1756-ESMNSEXT, 1756-L71, 1756-L71K, 1756-L72, 1756-L72K, 1756-L73, 1756-L73K, 1756-L73XT, 1756-L74, 1756-L74K, 1756-L75, 1756-L75K
Topic
Product Advisories
Insert the Controller into the Chassis
Insert the Key
Install the SD Card
Install the ESM
Specifications
Additional Resources
ControlLogix® 5570 Controllers provide a common control engine with a common development environment for all control disciplines.
• Supports Integrated Motion on EtherNet/IP™, integrated Sercos motion, and analog motion
• Supports full controller redundancy and Removal and Insertion Under Power (RIUP)
• Communicates via EtherNet/IP, ControlNet®, DeviceNet®, Data Highway Plus™, Remote I/O, SynchLink™, and third-party process and device networks
• Controllers with a 'K' in the catalog are conformal coated for extended protection in harsh, corrosive environments.
• ControlLogix-XT™ controllers are designed for temperature extremes.
• Offers chassis with up to 17 slots in standard, conformal coated, and extreme temperature versions
Summary of Changes
This manual contains new and updated information as indicated in the following table.
Topic
Added Plug Attention Statement
Specifications
Page
3
5
5
5
5
6
7
Page
4
6
