- Page 1 User Manual MicroLogix 1400 Embedded Web Server Bulletin 1766 Controllers...
- Page 2 In no event will Rockwell Automation, Inc. be responsible or liable for indirect or consequential damages resulting from the use or application of this equipment.
- Page 3 Added an important note about Write access 14, 30 Added important information about removing the functionality to change data table files Added important information about the possibility of data loss during firmware update using ControlFLASH Rockwell Automation Publication 1766-UM002E-EN-P - June 2019...
- Page 4 Chapter Summary of Changes Summary of Changes Notes: Rockwell Automation Publication 1766-UM002E-EN-P - June 2019...
-
Page 5: Table Of Contents
Data Table Memory Map ....... . 37 Rockwell Automation Publication 1766-UM002E-EN-P - June 2019... - Page 6 HTML Pages..........39 User Provided Pages Generating Custom Data Table Monitor Pages ....41 Index Rockwell Automation Publication 1766-UM002E-EN-P - June 2019...
-
Page 7: How To Use This Chapter
MicroLogix 1400 Embedded Web Server How to Use This Chapter Rockwell Automation® offers enhanced MicroLogix™ 1400 controllers for your EtherNet/IP control systems so you can monitor data remotely via web pages. This chapter shows how you can use a MicroLogix 1400 controller in your control system. -
Page 8: Connect The Micrologix 1400 Controller To The Network
If your network does not have a BOOTP server, use one of the methods described in the MicroLogix 1400 Programmable Controllers User Manual 1766-UM001 to assign an IP address to the MicroLogix 1400 controller. Rockwell Automation Publication 1766-UM002E-EN-P - June 2019... - Page 9 For more information, see Knowledgebase article 732398 - How to disable the web server in MicroLogix 1100 and 1400. Note: You will need to log in using your TechConnect? Account User Name and Password. Rockwell Automation Publication 1766-UM002E-EN-P - June 2019...
-
Page 10: Navigate The Micrologix 1400 Controller
You navigate the web server’s web pages by using the navigation panel on the left of the screen. There are also tabs across the top you can click to navigate the 1400 Controller folders containing documents. Rockwell Automation Publication 1766-UM002E-EN-P - June 2019... - Page 11 Tabs across the top match the documents within a folder, as shown in the left navigation panel. Click folders to open and close additional levels of information. Click a document to display a web page showing specific information. Rockwell Automation Publication 1766-UM002E-EN-P - June 2019...
- Page 12 Chapter 1 MicroLogix 1400 Embedded Web Server Notes: Rockwell Automation Publication 1766-UM002E-EN-P - June 2019...
-
Page 13: How To Use This Chapter
A data view consists of an HTML file and an XML file with data file information. The HTML file is in a readable ASCII format. It contains the File Name, File Type, # of Element, and Access Group. Rockwell Automation Publication 1766-UM002E-EN-P - June 2019... -
Page 14: Change An Access Group
For MicroLogix 1400, revision 21.006 or later, Write access is not supported and is listed as Invalid from the drop-down selection. Rockwell Automation Publication 1766-UM002E-EN-P - June 2019... -
Page 15: Monitor Data Views And Data Table File
Each file contains a hyperlink that takes you to the specific Data Views page for that file. When you click a particular file, the Data Views page appears, displaying the contents of the data table file you selected. Rockwell Automation Publication 1766-UM002E-EN-P - June 2019... -
Page 16: Change Data Table Files
Administrator access level can change the Data Table Files. When you click N7 in Data Views, Data Writable appears beside a Data File Type (Integer here) as shown below. How to Change a Data File Type In the steps that follow, a Binary type is assumed. Rockwell Automation Publication 1766-UM002E-EN-P - June 2019... - Page 17 2. Double-click the data that you want to change, then the background color turns pink. 3. Enter a value and either press Enter or click an area in the screen, then a confirmation window appears. Rockwell Automation Publication 1766-UM002E-EN-P - June 2019...
-
Page 18: Information On String Data File Types
• When using only special characters, you can enter up to 37 characters. • When using special characters in combination with alphanumerics, you can enter up to 113 characters as illustrated by the formula: (alphanumeric characters) + (special characters x 3) < 113. Rockwell Automation Publication 1766-UM002E-EN-P - June 2019... -
Page 19: Disable Web View
Web View Disable checkbox as shown below. Any data file property changes must be made offline and downloaded to the processor or later. Rockwell Automation Publication 1766-UM002E-EN-P - June 2019... - Page 20 Chapter 2 Use Data Views to Access Controller Data Notes: Rockwell Automation Publication 1766-UM002E-EN-P - June 2019...
-
Page 21: How To Use This Chapter
Overview of the current configuration of the Diagnostics Diagnostic Overview MicroLogix 1400 controller → Summary of the network settings configured for Diagnostics Network Settings the MicroLogix 1400 controller → Ethernet statistics Diagnostics Network Status Rockwell Automation Publication 1766-UM002E-EN-P - June 2019... - Page 22 Current Ethernet Connections current number of active connections Incoming Ethernet Connections current number of incoming connections Outgoing Ethernet Connections current number of outgoing Ethernet connections Ethernet Connection Limit maximum number of Ethernet incoming/outgoing connections Rockwell Automation Publication 1766-UM002E-EN-P - June 2019...
- Page 23 Default Gateway gateway address for the controller Primary Server Name DNS server names, if using DNS addressing Secondary Server Name Domain Name domain name for the web server module, if using DNS addressing Rockwell Automation Publication 1766-UM002E-EN-P - June 2019...
-
Page 24: Network Status
Deferred Transmissions Frames for which first transmission attempt is delayed because the medium is busy Late Collisions Number of times a collision is detected later than 512 bit-times into the transmission of a packet Rockwell Automation Publication 1766-UM002E-EN-P - June 2019... - Page 25 Times that the carrier sense condition was lost or never asserted when attempting to transmit a frame MAC Receive Errors Frames for which reception on the Ethernet interface failed due to an internal MAC sublayer receive error CRC Errors Frames for which CRC error is detected Rockwell Automation Publication 1766-UM002E-EN-P - June 2019...
- Page 26 Chapter 3 Monitor Diagnostics Notes: Rockwell Automation Publication 1766-UM002E-EN-P - June 2019...
-
Page 27: Chapter 4 Server Settings
Provided Pages on page 39. If Simple Web Page is selected, the simple web page is shown. For default home page, enter the IP address in the URL address bar, for example, http://192.168.0.10/index.htm. Rockwell Automation Publication 1766-UM002E-EN-P - June 2019... - Page 28 Chapter 4 Administrative Settings Notes: Rockwell Automation Publication 1766-UM002E-EN-P - June 2019...
-
Page 29: How To Use This Chapter
For firmware revision 21.006 or later, if you log into the web server as an administrator or guest for the first time, a message box prompts you to change the default password. You cannot proceed to the next step without changing the default password. Rockwell Automation Publication 1766-UM002E-EN-P - June 2019... -
Page 30: User Accounts And Privilege Classes
Administrator protection Server Setting page Administrator protection User Management page Administrator protection For MicroLogix 1400, revision 21.006 or later, Write access is not supported and is listed as Invalid from the drop-down selection. Rockwell Automation Publication 1766-UM002E-EN-P - June 2019... - Page 31 If you use Internet Explorer, the number of characters allowed for a IMPORTANT user ID or password depends on how many characters “fit in the box.” Larger characters (such as “W”) take more room and reduce the total number of allowed characters. Rockwell Automation Publication 1766-UM002E-EN-P - June 2019...
-
Page 32: Recover With Unknown Password
Update the firmware using ControlFLASH™ to initialize both user accounts and the access level of data view. Password Updating firmware using ControlFLASH™ may lead to loss of IMPORTANT important data. Back up data before the update to avoid data loss. Rockwell Automation Publication 1766-UM002E-EN-P - June 2019... - Page 33 The following topics appear on the home page main menu, as shown below: · Module Information · Ethernet Configuration · Diagnostic Information · Data Table Memory Map · User Provided Pages Rockwell Automation Publication 1766-UM002E-EN-P - June 2019...
-
Page 34: Chapter 6 Device Information
This page displays a table with information about the current Ethernet configuration parameters. Included are the module’s IP address, the subnet mask, gateway address, the Ethernet hardware address and whether BOOTP is enabled. Rockwell Automation Publication 1766-UM002E-EN-P - June 2019... -
Page 35: Diagnostic Information
Also included are the name server, secondary name server, and the default domain name parameters, if configured. Diagnostic Information This section gives you access to the various diagnostic information screens that are available. Rockwell Automation Publication 1766-UM002E-EN-P - June 2019... - Page 36 Chapter 6 Simple Web Pages The diagnostic screens automatically refresh using a time that is configurable by the user and defaults to 15 seconds. Rockwell Automation Publication 1766-UM002E-EN-P - June 2019...
-
Page 37: Data Table Memory Map
Read access group user account. Each file contains a hyperlink that takes you to the specific Data Table Monitor page for that file. When you click a particular file, the Data Table Monitor page Rockwell Automation Publication 1766-UM002E-EN-P - June 2019... - Page 38 Change Parameters button. To change the refresh data function back to the default of 15 seconds, click the Default field. To disable the refresh data function, click the Disable button. Rockwell Automation Publication 1766-UM002E-EN-P - June 2019...
-
Page 39: Html
· reference User Specified Pages in the MicroLogix 1400 controller by using the names user1.htm through user8.htm · to reference a page on the same controller, specify a URL such as /user2.htm Rockwell Automation Publication 1766-UM002E-EN-P - June 2019... - Page 40 Float files are always output in floating point format (“C”%g format). ASCII and STring files are always output as a null terminated text string. Binary files are always output as two binary bytes. Rockwell Automation Publication 1766-UM002E-EN-P - June 2019...
-
Page 41: Generating Custom Data Table Monitor
If the file_type is I, O or S, the file_number does not need to be specified, but the file_element must be specified. If the file_type is not one of the three special files, the file_number must Rockwell Automation Publication 1766-UM002E-EN-P - June 2019... - Page 42 5. Double-click the file to select it. 6. Click OK. 7. Repeat this process for each user page file. 8. When all user page files have been imported, go online with your MicroLogix 1400 controller processor. Rockwell Automation Publication 1766-UM002E-EN-P - June 2019...
- Page 43 Chapter 7 9. Select the User Provided Pages link to view the User Provided Pages menu, as shown in the following example: Click the User Provided Page #X to display that specific page. Rockwell Automation Publication 1766-UM002E-EN-P - June 2019...
- Page 44 Chapter 7 User Provided Pages Notes: Rockwell Automation Publication 1766-UM002E-EN-P - June 2019...
- Page 45 22 user management 29 Ethernet statistics 24 user provided pages 39 network settings 23 disable web view 19 write 9 Ethernet configuration 34 generating custom data table monitor pages 41 HTML pages 39 Rockwell Automation Publication 1766-UM002E-EN-P - June 2019...
- Page 46 Chapter 1 Notes: Rockwell Automation Publication 1766-UM002E-EN-P - June 2019...
- Page 48 Rockwell Automation representative. New Product Satisfaction Return Rockwell Automation tests all of its products to ensure that they are fully operational when shipped from the manufacturing facility. However, if your product is not functioning and needs to be returned, follow these procedures.
