Operating Instructions
Battery Capacity
Push the B Button to show the
battery capacity (shown as amp hours)
Icons Displayed: Amp Hour Symbol (Ah),
Arrow, Battery SOC, Sun
8.5 Errors
Over Voltage
If the GP-PWM-10 experiences a battery
over voltage (15.5V), the controller will
stop operating and the display will begin
to flash with all icons. The controller will
resume operating when the error is
cleared.
Icons Displayed: All symbols
Low Voltage
If the battery state of charge reaches 0%,
the battery SOC symbol will show the
text "LOW" beneath it. The controller will
continue operating in this condition and
will only stop operating if the voltage drops
below 6 volts.
Icons Displayed: Battery SOC, LOW
page 14 | gpelectric.com
