6
1. Sun = Daytime: PV Charge Current
Moon = Nighttime: No Charge Current
2. Battery State of Charge
3. Low Battery Voltage
Battery State of Charge Chart
Shows only after full Boost
or Equalization Cycle
>= 12.6V
>= 11.8 -12.6V
> 11.0 -11.8V
battery voltage - 11.0V
SOC =
page 10 | gpelectric.com
1
x 90%
1.8V
7. Display Symbols
4.USB Charging On
5. Battery Type Profiles
6. Controller tries to keep battery at boost
voltage or higher (automatic setting)
<= 11.0V
Shows only after full Boost
100%
or Equalization Cycle
90%
>= 12.8V
0%
<= 11.0V
< 12.8V and > 11.0V
2
3
4
5
