GB
www.lehmann-locks.com
M410 Keypad lock
(M410 TA03 / M410 TA03 pro)
Operating Instructions
Content
Page
General system description / Operating description ....................................................... 2
System components & package contents ........................................................................ 4
Dimensions ...................................................................................................................... 5
Getting started & changing battery ................................................................................. 6
Emergency power supply / Installing the bolt protector ................................................. 7
Mounting the locking system .......................................................................................... 8
Structure of the keypad TA03 .......................................................................................... 9
Free Code mode ............................................................................................................ 10
User changes the Fixed Code / Switching to Free Code mode ...................................... 12
Changing the master code ............................................................................................. 13
Changing the emergency opening code ........................................................................ 14
Emergency opening / Reset to factory settings ............................................................. 15
Automatic locking in Fixed Code mode ......................................................................... 16
Automatic opening in Free Code mode ......................................................................... 17
with NFC app ................................................................................................................. 18
Battery warning ............................................................................................................. 19
Firmware update / Disposal .......................................................................................... 20

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the M410 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for LEHMANN M410

Summary of Contents for LEHMANN M410

  • Page 1: Table Of Contents

    Emergency opening / Reset to factory settings ............. 15 Automatic locking in Fixed Code mode ................. 16 Automatic opening in Free Code mode ................. 17 Activation and deactivation of acoustis signals / Configuration of M410 TA03 PRO with NFC app ......................... 18 Battery warning ......................19...

  • Page 2: General System Description / Operating Description

    The M410 TA03 / M410 TA03 pro (keypad) locking system is a furniture lock with a motor-driven locking bolt intended for use in the home and office. The lock M410 TA03 pro can be configured either manually or with the LEHMANN Config app on a smartphone.

  • Page 3: Safety Precautions / Care & Maintenance / Technical Specifications

    Replace the battery in good time, but at the latest when the visual battery warning on the keypad lights up. TECHNICAL SPECIFICATIONS Power supply Battery type: 1 x CR123A Operating temperature -5 °C to +60 °C Storage temparature -25 °C to +70 °C Type designation Lock M410: SLI2CBM6 Lock M410 pro: SLI2CPM6 Keypad TA03: MAIIC3M6...

  • Page 4: System Components & Package Contents

     Components: 6. Striker plate 4005 1. Lock M410 / M410 pro 7. Keypad TA03 2. 4 x pan-head screw (3,5 x 35 mm) 8. Cover of keypad TA03 3. Cable 9.

  • Page 5: Dimensions

    DIMENSIONS Lock M410 / M410 pro Striker plate 4005 Keypad TA03 without labeling clip For Ø19 x 16 Für Stanzbild ø19 x 16 15,9 All figures in mm.

  • Page 6: Getting Started & Changing Battery

    GETTING STARTED & CHANGING BATTERY Make sure that the lock and keypad are correctly connected to each other by the connection cable. Pay attention to the correct connection of the plugs and sockets. IMPORTANT: Only use one CR123A primary battery! Insert the battery first with the Close the battery compartment minus pole as shown above.

  • Page 7: Emergency Power Supply / Installing The Bolt Protector

    EMERGENCY POWER SUPPLY The locking system has the option of an emergency power supply in case of an empty battery. Hold a 9V battery to the Insert the two guide lugs of the contacts at the keypad cover into the recesses. Press while entering the code or the cover until it clicks into Insert the pin into the hole...

  • Page 8: Mounting The Locking System

    MOUNTING THE LOCKING SYSTEM Mounting position of lock M410 / M410 pro Mounting position of keypad TA03 Door Door Door Door Exemplary for a right door. Mounting position of striker plate 4005 Door Sidewall Door X + 13* 13** Inlay doors *...

  • Page 9: Structure Of The Keypad Ta03

    STRUCTURE OF THE KEYPAD TA03 LED display Numbers 0-9 Cancel Enter Trip point for removing the cover for emergency power supply You can cancel any operation at any time by pressing the cancel button . When the cancel button is pressed, there is one short red flashing.

  • Page 10: Bolt End Position Scan Function / Factory Settings / Opening & Closing In Free Code Mode

    BOLT END POSITION SCAN FUNCTION The locking system also has a bolt end position scan function. If, during the locking process, the bolt does not reach its end position, the LED display flashes red for four times. The lock is not locked. Check the correct mounting positi- on of the lock, the bolt protector and the striker plate.

  • Page 11: Switching To Fixed Code Mode / Opening & Closing In Fixed Code Mode

    SWITCHING TO FIXED CODE MODE The lock must be in open position. There must be no battery warning. The fixed code must be 3 to 10 digits. If you have already changed the default master code, enter your valid master code here. In order to confirm the master code, press the keys simultaneously.

  • Page 12: User Changes The Fixed Code / Switching To Free Code Mode

    USER CHANGES THE FIXED CODE The lock must be in open position. There must be no battery warning. The fixed code must be 3 to 10 digits.. If you have already changed the default fixed code for the user, enter your valid code here. The previous code will be overwritten by entering the new code.

  • Page 13: Changing The Master Code

    After you have successfully switched to Free Code mode, you can operate the lock with any random code (3 to 10 digits). Please refer to page 11, „Opening & closing in Free Code mode”. Switching to Free Code mode deactivates the function „Automatic closing in Fixed Code mode“ or „Automatic opening in Free Code mode“...

  • Page 14: Changing The Emergency Opening Code

    CHANGING THE EMERGENCY OPENING CODE It is highly recommended that you change the default emergency opening code and to choose the longest possible and secure emergency opening code. The lock must be in open position. There must be no battery warning. The emergency opening code must be 3 to 10 digits.

  • Page 15: Emergency Opening / Reset To Factory Settings

    EMERGENCY OPENING If you have already changed the default emergency opening code, enter your valid emergency opening code here. Enter emergency opening code (example: factory settings) Keys Lock opens Display After an emergency opening in the Fixed Code mode, the lock can be used again normally with the previously pro- grammed fixed code.

  • Page 16: Automatic Locking In Fixed Code Mode

    AUTOMATIC LOCKING IN FIXED CODE MODE The lock must be in open position. There must be no battery warning. This feature can only be activated in Fixed Code mode. If you have already changed the default master code, enter your valid master code here. In order to confirm the master code, press the keys simultaneously.

  • Page 17: Automatic Opening In Free Code Mode

    AUTOMATIC OPENING IN FREE CODE MODE The lock must be in open position. There must be no battery warning. This feature can only be activated in Free Code mode. If you have already changed the default master code, enter your valid master code here. In order to confirm the master code, press the keys simultaneously.

  • Page 18: Activation And Deactivation Of Acoustis Signals / Configuration Of M410 Ta03 Pro With Nfc App

    CONFIGURATION OF M410 TA03 PRO WITH NFC-APP The lock M410 TA03 pro can be configured either manually or with the LEHMANN Config app. After putting the app into operation on an Android smartphone or Apple iPhone, configuration changes can be made via the app.

  • Page 19: Battery Warning

    To transfer configurations or direct commands to the lock, first check the position of the NFC antenna on your smartphone. Activate the NFC interface on your smartphone. Click on the „Transfer“ button in the LEHMANN Config App. Hold the NFC antenna of your smartphone at the marked location on the corresponding lock. The NFC antenna in the lock is located in this area.

  • Page 20: Firmware Update / Disposal

    (for example, technical need). To update the firmware you need the software LEHMANN Firmware Updater. The software can be found on the website www.lehmann-locks.com under Electronic Locking Systems and there under Software Solutions. The individual steps for updating the firmware are described in the software.

This manual is also suitable for:

M410 ta03M410 ta03 pro
