CHEMICAL PLUNGER PUMP
INTRODUCTION
Thank you for purchasing this CLARKE chemical plunger pump,
Suitable for water, alcohol, petroleum, diesel, paraffin, lubricant, NOT SUITABLE for water-based chemicals, acid or
alkaline.
Before attempting to use this product, please read this manual thoroughly and follow the instructions carefully.
LIST OF CONTENTS
• 1 x Pump
• 1 x Handle assembly
• 2 x Nuts and Bolts
ASSEMBLY
1. Remove the nut from the pump as shown.
FITTING THE
1. Connect the handle as shown and secure at
each point using the small nuts and bolts.
Parts & Service: 020 8988 7400 / E-mail: Parts@clarkeinternational.com or Service@clarkeinternational.com
FITTING THE OUTLET TUBE
HANDLE ASSEMBLY
• 1 x Outlet tube
• 1 x Extension Inlet tube
• 1 x 2 piece telescopic extension with filter
2. Place the nut over the outlet tube and back
onto the pump
FITTING THE TELESCOPIC EXTENSION TUBE
1. Fit the telescopic extension with filter together
as shown
MODEL NO: CPPPSS
PART NO:
PART NO: 6499635
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Clarke CPPPSS
Summary of Contents for Clarke CPPPSS
- Page 1 PART NO: 6499635 CHEMICAL PLUNGER PUMP INTRODUCTION Thank you for purchasing this CLARKE chemical plunger pump, Suitable for water, alcohol, petroleum, diesel, paraffin, lubricant, NOT SUITABLE for water-based chemicals, acid or alkaline. Before attempting to use this product, please read this manual thoroughly and follow the instructions carefully.
- Page 2 FITTING THE PUMP TO A BARREL 1. Fit the telescopic extension with filter to the pump. • You can fit the extension inlet tube in between if required. 2. Adjust the telescopic extension tube to the required length. • The bottom of the telescopic extension should be just off of the bottom of the barrel when fitted.
- Page 3 CHEMICAL RESISTANCE TABLE • Room Temperature • % Say Mass Concentration WATER ACIDS ALKALI PETROLEUM HALOGENS ALCOHOL THINNER BASED Sea Water Acetic Acid Potassium Silicone Oil Calcium Ethanol 96% Acetone Hydroxide Chloride 10% Boric Acid Sodium Copper Glycerine Hydroxide Sulphate solution 50% Citric Acid Potassium...
- Page 4 Parts & Service: 020 8988 7400 / E-mail: Parts@clarkeinternational.com or Service@clarkeinternational.com...
