Scheppach RoboCut XL600 Manual page 35

Wheel motor
E2
blocked
E3 Cutter disc blocked
Obstacle
E4 sensor trigger not
reset
The mower was
E5
lifted
Roll-over sensor
E6
was triggered
Inclination sensors
E7
were triggered
Docking/recharging
E8
failed
The robotic lawn-
E9
mower is stuck
Protection of the
E10
battery
E11 No boundary signal
Charging current
E13
too high or too low
EE Error unknown
Battery thermal
BP
protection
Robotic lawnmower
locked (PIN entered
LOCK
incorrectly too
many times)
1. Switch the mower off. Move the mower to an area that is free of obstacles. Press
the "START" button and then the "OK" button.
2. If the error message is still displayed, switch off the product. Turn the mower up-
side down and check what is preventing the wheels from turning.
3. Remove the objects blocking the wheel(s), turn the mower over.
4. Press the "START" button and then the "OK" button.
1. Switch the mower off.
2. Turn the mower upside down and check what is preventing the blades from turn-
ing.
3. Remove the objects and turn the mower over.
4. Place the mower in an area with short grass.
5. Press the "START" button and then the "OK" button.
1. If the error still occurs, contact your specialist dealer.
1. Switch the mower off.
2. Move the mower to an area that is free of obstacles. Press the "START" button
and then the "OK" button.
3. If the error message is still displayed, switch off the product. Turn the mower up-
side down and check if there is anything preventing the front axle from moving.
4. Remove all obstacles, turn the mower over and switch it on. Press the "START"
button and then the "OK" button.
1. Position the mower.
2. Press the "START" button and then the "OK" button.
1. Switch the mower off.
2. Move the mower to an area in your lawn with level ground.
3. Switch the mower on. Press the "START" button and then the "OK" button.
1. Check that there is 1 metre of space before and after the charging station, without
obstacles or corners.
2. The charging station must be placed on level ground.
3. Manually place the mower in the charging station for charging. After the mower is
fully charged, press the "START" and then the "OK" button.
1. Place the robotic lawnmower in an area that is free of obstacles.
2. If the error still occurs, contact your specialist dealer.
1. If the temperature is too high, wait until the temperature has dropped. If the tem-
perature is too low, wait until the temperature is above 5 degrees Celsius.
2. If the error message is still displayed, replace the battery. Re-start the mower.
Press START and then OK.
3. If the error still occurs, contact your specialist dealer.
1. When the mower is in the working area, check the charging station LED indica-
tor. If it lights up red, make sure that the boundary wires are well connected to
the terminals on the charging station. If the problem persists, check whether the
boundary wires have been cut.
1. Check docking area.
2. If the error still occurs, contact your specialist dealer.
1. Re-start the mower.
2. If the error still occurs, contact your specialist dealer.
1. Switch the mower off.
2. Move the mower to an area in your lawn with level ground.
3. Check the temperature of the battery.
4. If the temperature is too high, let the battery cool down.
5. If the temperature is too low, wait until the temperature is higher than 5°C.
6. Re-start the mower.
7. If the error still occurs, replace the battery.
8. If the error still occurs, contact your specialist dealer.
1. Wait 10 minutes and then enter the PIN again.
2. Do not switch the robotic lawnmower off.
3. If the error still occurs, contact your specialist dealer.
