5.09

Alarms Menu

The Alarms menu lists alarms, if any, that may occur duing operaton of the UPS. Alarms will not prevent
operation of the UPS. Alarms are visually indicated by a flashing RED LED on the front panel. In the event of
multiple alarms, use the Scroll button to see if there are additional faults.
ALARM STATUS
-- NO ALARM --
Alarms that may occur are described below.
• Overload – The output is overloaded. Remove the overload to correct this alarm.
• Batt Temp High – The battery temperature is above the rated operating conditions. Check the bat-
tery string for damage or faulty temperature probe.
• Batt Temp Low – The battery temperature is below the rated operating conditions.
• Fan Alarm – The fan has failed. Contact Multilink Engineering Support.
• Input Brkr Open – The AC input breaker is open.
• Batt Brkr Open – The battery breaker is open.
• Battery Test – Indicates that a battery test is currently running.
• Batt Low – The battery voltage is low. Verify string is attached to UPS and breaker is closed.
• Weak Battery – Check condition of the batteries in the string. Replace each if necessary.
Temp probe – Verify that the temperature probe is attached to the UPS. If so, check for continuity in
the plug. Replace if necessary.
• Bad Frequency – The frequency of the AC input is outside of the rated operating conditions.
• Utility Fail – The AC input voltage is below the operating specs of the UPS.
• Line High – The AC input voltage is nearing or greater than the high operating specs of the UPS.
• Line Low – The AC input voltage is nearing or lower than the low operating specs of the UPS.
Multilink Inc. 580 Ternes Ln. | Elyria,OH 44035 | 440.366.6966 | www.gomultilink.com
26
This menu shows the present alarms occurred by the UPS. See details below.
Use the scroll button to view multiple alarms, if present.
