Menu Options and Descriptions
Status Menu: Displays the current operating conditions for the UPS
Control Menu: Displays UPS Configurable items. This menu is password protected.
Fault Status Menu: Displays any faults that may have occurred during operation of the UPS.
Alarm Status Menu: Displays any alarms that may be present during operation of the UPS.
Event Status Menu: Displays a list of events with time stamps for each event that has occurred.
Relay Menu: Describes each of the 8 relays available on the front panel of the UPS.
5.05
UPS Main Menu
MULTILINK
EP1100
IN: 120V
OUT:120V
BAT: 55V
LINE
RLY:
-- OFF --
State of operation will appear on the bottom line of this menu. They are described as:
• LINE: UPS is powered from the qualified AC utility line voltage.
• INVERTER: Utility line voltage is absent or unqualified and the UPS is powered from the battery string.
• QUAL: Utility line voltage is being qualified for use.
• BUCK: Occurs when utility line voltage is high. This feature has two stages, BUCK1 and BUCK2.
• BOOST: Occurs when utility line voltage is low. This feature has two stages, BOOST1 and BOOST2.
• STANDBY: Indicates the power supply output is shutdown and waiting for the presence of utility
line voltage or acceptable battery voltage.
• BYPASS: The output of the UPS is bypassing the use of the inverter.
• TEST: A battery test is currently in process.
At any time, press any the Select or Scroll buttons to enter the menu item displayed. Below are each of the
six main menus with their respective submenus descirbed.
5.06
Status Menu
The Status menu provides parameter values such as input voltage, frequency, event count, etc.. Each item
will display its respective value as measured. Use the Scroll button to view items. Use the Cancel button to
return to the prevous menu. Each parameter will be descirbed below.
Multilink Inc. 580 Ternes Ln. | Elyria,OH 44035 | 440.366.6966 | www.gomultilink.com
22
This line displays the manufacturer and model type.
The line reports input and output voltage
This line reports the battery voltage and mode of operation.
This line reports active relay alarms
Each soft key has a dedicated function as described above
