Controls Menu - Multilink EP 1100 Installation & Operation Manual

IN/OUT STATUS
VI: 120V VO:119V
FQ: 60HZ IO:3.0A
OUT PWR: 360W
BATTERY STATUS
VOL:55.0V TMP:20°C
CHGR CUR: 5.0A
RUN TIME: 250 MIN
NETWORK STATUS
IP: 192.168.100.1
MAC ADDRESS
00:14:81:00:FC:D8
System Status
S. NO: 191951401
VER: 3.0.11
12-18-19 12:30:00 PM
5.07

Controls Menu

The Controls menu is password protected and provides configurable parameters and UPS control func-
tions. Each item may have one or more selectable options when selected. When an item is selected to be
changed, the option with flash. Press the Scroll button to select a different option and press Enter to con-
firm this change. The item will stop flashing once it has been selected. Press cancel at any time to abort
making a change or to return to the previous menu. The default factory password is "1111".
ENTER PASSWORD
PWD:1111
CONTROL MENU
INVERTER DISABLE
FORCEINV OFF
BYPASS OFF
Multilink Inc. 580 Ternes Ln. | Elyria,OH 44035 | 440.366.6966 | www.gomultilink.com
Input Voltage (VI) and Output Voltage (VO).
Input/Output Frequency and Output Current (IO).
Calculated Output Power in Watts
Batt string voltage and remote temperature sensor reading. Measured battery
charger current.
Estimated runtime. This value is only an estimate and varies on battery life, load
conditions, and inverter operation.
Displays the currently assigned IP address.
This is the MAC address of the embedded network card.
This is the serial number of the unit.
Firmware version installed for the EP1100.
Current Date and Time
Press the Scroll button to select "1" then press the "Select" button to move to
the next digit. Digits will change to asterisk when entered.
Inverter: Enable by default, may be disabled to prevent inverter operation
Force Inverter: Disable by default, may be turned on to force inverter operation.
Bypass: off by default, may be enabled by user to bypass
Inverter and charger operation.
© Multilink Inc. 2020 • All Rights Reserved
23
