SIMPLICITY PLUS INSTALLATION MANUAL
Installation Manual Modification History
***Do Not Print this Page when creating PDF Of the manual***
Issue Date
3.09 01/08/2011
3.10 14/06/2012
3.11 16/7/2012
3.12 26/7/2012
3.13 29/8/2012
3.14 5/3/2015
3.15 25/5/2017
3.16 21/9/2017
Approved Document No: GLT.MAN-107
Issue 3.16 Author: NRPJ
www.acornfiresecurity.com
Changes
Version before Modification history page added.
Corrected mains voltage references to 230V AC.
Updated product images.
Fixed formatting & spelling/punctuation issues. (Incorrectly
marked as 3.2)
Fixed Formatting
Updated Device wiring Drawings
Removed one man test mode reference.
Amended Cable type
Added Battery Type
Added note that zones 1-7 must have at least 2 devices
Added information about sounder start time
Deleted "enclosure designed for 7AH" comment in battery calc
section – refers to Original Plastic version of panel.
Corrected Max loops/Devs to reflect 2 loop version (sect 22.2)
NOTE: Use PDF Printer – Save as PDF causes problem on zone
diagram.
Added Max Zones Per System, Max points per system
Added I/O config information
Updated for MKII Protocol operation & devices
Corrected general typos
Updated BS5839 references to latest version
Updated wiring info to MKII devices
Mentioned Switch 8 always on for a simplicity
Updated sounder selection to reflect current sounders
Corrected panel name entry
Updated interface setting to show all input & Output options
Updated language list
Changed verification time to minimum of 1 minute
Added missing menu items
Updated Company name to Zeta Alarms Limited
Corrected CPR ref on CE box from 0359-CPR-0145 to 0359-
CPR-00145.
Date: 21/09/2017
