15. VIEWING PANEL INFORMATION

15.1 MENU STRUCTURE

To help locate the different features available, the menu structure of the simplicity panel is shown here.
MENU LAYOUT
MAIN MENU SUB MENU 1
CONFIGURATION MENU 1 – THE USER MENU
1:Loop Contents -
2:Device Status -
3:Event logs VIEW EVENT LOG
1: Alarms
2: Faults
3: System
4: All
CONFIGURATION MENU 2 – THE ENGINEER MENU
4:Configure Loops -
5:Edit Device -
6:Config System System Menu
1: Clock
2: Zones
3: Alarms
4: Timing
5: Misc
6: Reset
Approved Document No: GLT.MAN-107
Issue 3.16 Author: NRPJ
www.acornfiresecurity.com
SUB MENU 2
-
-
-
-
-
-
-
-
-
-
Alarm Operation
1: Det
2: MCP
3: SOUNDER
4: Bases
5: I/O
6:Relay
Alarm Timing
1: Zonal to Common
2: Alarm Verify
Misc Settings
1: Language
2: Version Info
3: Protocol
4: Mode
5: Name
6: Tone
Reset Settings
1: Logs
2: Zones
3: Panel
4: Devices
6: All
Date: 21/09/2017
www.acornfiresecurity.com
DESCRIPTION
View quantity of each device type configured on the
loop
View the status of an individual device (Status –
normal/fault/alarm, Analogue value, device label
Configure the loop
Edit device label (press enter for cursor)
Turn on detector LED
Ring associated sounder
Select alarm verification
Turn off associated sounder at this address
Disable this device.
Select specific I/O Operation for an I/O unit
Adjust time & date
Change zone boundaries
Choose detectors to cause zonal alarm or common alarm
for sounders. There is also an option for alarms from
detectors not to ring any sounders.
Choose MCP to cause zonal alarm or common alarm for
sounders
Select if the sounders have a zonal to common time out
when triggered zonally
Select if associated sounder bases work common or
zonal
Select default I/O type
Chose if the on board fire relay operates for all alarms,
detector alarms only, or manual call point alarms only
Select the delay for all the sounders to operate after a
zonal alarm
Select alarm verification time
Select LCD language
Displays the firmware versions
Select device protocol
Select maintenance or running mode. Maintenance
mode reports all faults as soon as the panel detects
them. Running mode requires a fault to be present for
around 30 seconds before reporting
Allows a panel name to be entered (2 x 20 characters)
Allows the alarm tone to be selected. See sounder
manuals for further information.
Erases event logs
Resets the default zone boundaries
Resets panel to default alarm & timing settings
Erases loop contents from memory, clears device labels,
resets verification & sounder base settings to default.
Resets all configuration settings, but preserves event log.
