Simplicity system, we refer to this as the Zonal to Common sounder time.
Select option 3 (Sounder) from the alarm operation menu. This zonal to common sounder time
can either be disabled, i.e. alarms stay zonal, or it can be enabled, i.e. all the sounders will start
after the programmed time delay.
To alter this delay, go to the System Menu and select option 4 (Timing)
The panel will bring up the following menu. Select option 1 (Zonal to common)
The panel will now show the currently selected delay time. This can be set between 30 seconds
and 10 minutes, in 15 second increments, using the previous and next buttons. Press enter to
confirm the selected time.

12.8.4 ASSOCIATED SOUNDER BASE SETTINGS

On previous Simplicity Panels, associated sounder bases have always been common acting.
There is now an option for them to be zonal. In the Alarm Operation Menu, select option 4
(bases).
Press Prev / Next to select common or Zonal operation, then press enter.
12.9 CHANGING THE ALARM RESPONSE – I/O UNITS
Because a system could have several I/O units, each reacting to different types of events the simplicity system adopts the
following method for configuring I/O units:-
1. Select a default I/O unit operation (This is done from the Alarm Operation Menu)
This will then be the default operation of all I/O units on the system.
2. Any I/O units which need a different operation can be edited individually from the edit device screen

12.9.1 TYPES OF I/O UNIT OPERATION

The simplicity now has the following types of I/O operation:-
Common Operates output on ANY alarm
Zonal Detector Operates its output on a DETECTOR alarm from its own ZONE
Zonal All Operates its output on any alarm from its own ZONE
Own Input Operates its output ONLY when its own INPUT is triggered
Panel Link Special type used for Inter-panel link. Output operates on any alarm , EXCEPT from its own
address, AND the input is non latching and behaves similar to class change.
Manual Alarm Operates output on ANY MCP alarm
Detector Alarm Operates output on ANY Detector alarm
Zonal MCP Operates its output on a MCP alarm from its own ZONE

12.9.2 SETTING DEFAULT I/O UNIT OPERATION

To set the simplicity panels default I/O operation, enter configuration menu 2, then select config
system to bring up the system menu.
Approved Document No: GLT.MAN-107
Issue 3.16 Author: NRPJ
www.acornfiresecurity.com
Date: 21/09/2017
www.acornfiresecurity.com
Sounder Operation
