SIMPLICITY PLUS INSTALLATION MANUAL
17.4 VIEWING DISABLEMENTS
When disablements have been programmed (either zone or device), the general disablement
LED will be lit. To view the disablements, press the GENERAL DISABLEMENTS button, and the
screen will show the following:
17.4.1 VIEWING DISABLED ZONES
To view which zones are disabled, press 1 and then scroll through all the zones, by pressing the disablement Select button
or the Next button.
If a zone is not disabled, the screen will show:
If a zone is disabled, the screen will show:
If there are one or more disabled devices in a zone, the screen will show this by the number of
Single Devices as follow.
(TIP: a quick way to enable several disabled devices is to disable the zone in which these
devices are located, then re-enable it)
17.4.2 VIEWING DISABLED DEVICES
To view which devices are disabled, press 2 and scroll through all the disabled devices, by pressing the Next button.
The screen will show:
Line 3 will flash between the device label and Device Disabled Message.
Approved Document No: GLT.MAN-107
Issue 3.16
Author: NRPJ
www.acornfiresecurity.com
Date: 21/09/2017
www.acornfiresecurity.com
Disablement
1: Zones
2: Devices
Zone Disablement
Zone
1
Zone Enabled
Disabled Devices:
0
Zone Disablement
Zone
1
Zone Disabled
Disabled Devices:
0
Zone Disablement
Zone
1
Zone Enabled
Disabled Devices:
2
Optical
Analog:
25
Normal
Device Disabled
Zone:01
Ad:016
PAGE 38
