FortiGate 6000F hardware assembly and rack mounting

To install transceivers

To complete this procedure, you need:
A FortiGate 6000F
l
Transceivers to install
l
An electrostatic discharge (ESD) preventive wrist strap with connection cord
l
1. Attach the ESD wrist strap to your wrist and to an available ESD socket or wrist strap terminal.
2. Remove the caps from the cage sockets on the FortiGate 6000F front panel.
3. Hold the sides of the transceiver and slide it into the cage socket until it clicks into place.
FortiGate 6000F Series 7.0.12 System Guide
FortiGate 6000Fs must be protected from static discharge and physical shock. Only handle or
work with FortiGate 6000Fs at a static-free workstation. Always wear a grounded electrostatic
discharge (ESD) preventive wrist strap when handling FortiGate 6000Fs.
Handling the transceivers by holding the release latch can damage the connector. Do not force
transceivers into their cage slots. If the transceiver does not easily slide in and click into place,
it may not be aligned correctly. If this happens, remove the transceiver, realign it and slide it in
again.
