Printer Power and Control Signals

A single cable connects the Controller and the Printer Body.
This cable can be up to 10 metres in length.
Both power and signals are present in the single multi-core cable.
To ensure robust signal integrity, the Controller to Printer link is via a twisted-pair RS-
422 interface.
The cable is terminated at each end by 37 way D type connectors, one male one
female.
The cable must be inserted into Controller and Printer Body and firmly secured prior to
switching on the unit.
