Printer configuration
Ribbon Winding
Range: Inside Winding or Outside
Winding
Default: Inside Winding
Ribbon Advance Distance
Range: 1 - 10mm (1 - 1000
mm*100)
Default: 1mm
Ribbon Spacer Width
Range: 0 to 55 mm
Default: 0
Ribbon Extra Wind
Range: 0 to 600 mm
Default: 0
Depending on which side of the ribbon the ink positioned, this allows you to
configure the Inside or Outside option.
This allows you to set the distance the ribbon advances between prints (in
addition to the length of the print)
When using Radial Ribbon Save this should be set to a minimum of 2 mm.
This allows you to configure the width of a ribbon spacer if one is being
used.
This allows you to configure the amount of additional wind on when a new
ribbon is fitted or the cassette is opened.
