Markem Imaje SmartDate X40 Instruction Booklet page 139

Printer configuration
Start Border
Range:
0 to 20.0 mm
Default: 2.0 mm Intermittent
Default: 4.0 mm Continuous
End Border
Range:
0 to 20.0 mm
Default: 2.0 mm Intermittent
Default: 0.5 mm Continuous
Head Clean Ribbon Count
Range: 0 to 1000
Default: 0
Missed Line Fault Threshold
Range: 0 to 5000
Default: 0
This allows you to set the distance over which the printhead is allowed to settle
after it has moved out, but before it starts to print.
This allows you to set the distance the printhead or ribbon is allowed to travel
after printing, but before the printhead is retracted.
This allows you to set the number of rolls of ribbon that must pass the printhead
before the Head Clean warning is issued.
This allows you to set the number of acceptable missed lines on an image be-
fore a fault is raised.
140 10055363-AB
