SIIG JU-H30112-S1 User Reference Manual

Superspeed usb 3.0 lan hub - type-c ready
Hide thumbs
1
2
3
4
5
6
7
8

Advertisement

Table of Contents

Introduction
The SuperSpeed USB 3.0 LAN Hub - Type-C Ready
adds three USB 3.0 ports and one Gigabit Ethernet
port (RJ45) through a USB Type-A or Type-C
port.
Key Features and Benefits
•
Includes Type-C (male) to Type-A (female)
adapter to use with the latest desktop or
laptop with USB Type-C port
•
SuperSpeed USB 3.0 interface supports data
transfer rates up to 5Gbps and backward
compatible with USB 2.0/1.1
•
RJ-45 connector provides instant connection
to wired network with speeds up to
1000Mbps, supports half and full-duplex
operation with Wake-on-LAN
04-1006A
SuperSpeed USB 3.0 LAN
Hub - Type-C Ready
User Reference Guide
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the JU-H30112-S1 and is the answer not in the manual?

Questions and answers

Related Manuals for SIIG JU-H30112-S1

Summary of Contents for SIIG JU-H30112-S1

  • Page 1 SuperSpeed USB 3.0 LAN Hub - Type-C Ready User Reference Guide Introduction The SuperSpeed USB 3.0 LAN Hub - Type-C Ready adds three USB 3.0 ports and one Gigabit Ethernet port (RJ45) through a USB Type-A or Type-C port. Key Features and Benefits •...

  • Page 2: Package Contents

    • Tuck-away USB cable design reduces cable mess and tangles, compact size provides great portability • Powered by USB port, no external power adapter required Package Contents • SuperSpeed USB 3.0 LAN Hub - Type-C Ready • Type-C to USB 3.0 A/F Adapter with rubber •...

  • Page 3: Specifications

    Specifications USB 3.0 Hub: VIA VL812-B2 Chipset LAN: Realtek RTL8153-CG Interface USB 3.0 Port 4 Ports 1x USB 3.0 Type-A, Male Connectors 3x USB 3.0 Type-A, Female & 1x RJ45, Female (Ethernet) USB 3.0 Hub: 5Gbps Max. Data Transfer Rate LAN: 1Gbps Compatible Networks 10/100/1000 Mbps (Full Duplex Support)
  • Page 4 • USB 3.0 Type-A: Connects to an available USB port of the computer • USB 3.0 ports (x3): Connects to USB devices such as mice, pen drives, and printers • RJ45 Ethernet Port: Connects to Ethernet network Windows Installation (for LAN connection) Note: Windows 7 and later have built in driver support for this adapter.
  • Page 5 After successful installation, click Finish. The adapter is ready for use. Windows Verification Right click Computer / My Computer on the desktop, and select Manage. Select Device Manager then expand Network adapters section. Realtek USB GbE Family Controller should be displayed. MAC Installation Insert the adapter into an available USB port.
  • Page 6 Application Adds three USB 3.0 ports and one Gigabit Ethernet port (RJ45) - Via USB Type-A Figure 2 - Via USB Type-C The included Type-C to USB 3.0 A/F Adapter converts the USB Type-C port which is found on the new 2015 MacBook and Chromebook Pixel ®...

  • Page 7: Technical Support And Warranty

    Step 1: Submit your RMA request. Go to www.siig.com, click Support, then RMA to submit a request to SIIG RMA or fax a request to 510-657-5962. Your RMA request will be processed, if the product is determined to be defective, an RMA number will be issued.

  • Page 8: Fcc Compliance Statement

    Fremont, CA 94538-3152, USA Phone: 510-657-8688 SuperSpeed USB 3.0 LAN Hub - Type-C Ready is a trademark of SIIG, Inc. SIIG and the SIIG logo are registered trademarks of SIIG, Inc. Microsoft and Windows are registered trademarks of Microsoft Corporation. All other names used in this publication are for identification only and may be trademarks of their respective owners.
