RH Teen DEVYN TUFTED TWIN BED Assembly Instructions

DEVYN TUFTED TWIN BED - ASSEMBLY INSTRUCTIONS
Phillips-head Screwdriver (not included)
1. Place the Headboard (C) flat on the floor covered with a protective material to prevent damage.
2. Stand the Headboard (C) upright and hook Headboard (C) into Side Rails (A), as shown in Diagram I.
3. Repeat the previous procedure with the Footboard (B), as shown in Diagram II.
4. Attach the Center Support Slat Foot (F) to the Center Support Slat (D), as shown in Diagram III.
5. Place the Center Support Slat (D) into the U-Shaped brackets on Side Rails (A), as shown in Diagram IV.
6. Place the Slat Roll (E) into the cleats on the inside of the Headboard (C) and Footboard (B). Screw the
ends of the Slats into the cleats using Screw (1), as shown in Diagram V.
DESCRIPTION
NO.
Screw (3cm)
1
Screw (5cm)
2
3
Page 1 of 2
Allen Key
Qty
14 Pcs
2 Pcs
1 Pc
