RH Teen Thalia Trundle Daybed Twin Assembly Instructions

PARTS INCLUDED

A [ 2 ] SIDE PANEL
[ ]
B 1 FRONT PANEL
1 [ ]
C HEADBOARD
1 [ ]
D
TRUNDLE
4 [ ]
E
SLAT
F 2 [ ] PLATFORM PANEL

TOOLS NEEDED

Phillips-head Screwdriver (not included)
ASSEMBLY INSTRUCTIONS
Bed must be assembled by at least two people.
Please read instruction carefully before assembling bed.
Use the above parts and hardware list to identify each component.
Keep all packing materials until assembly is complete to avoid loss of smaller parts.
1. Stand the Headboard (C) upright and hook Headboard (C) into Side Panels(A), as shown in Diagram I.
2. Screw the Allen Head Bolts (2) into the Side Panels (A) per-buried holes, then stand the Front Panel (B)
upright and attach Side Panels (A),
3. Place the Slats (E) into the U-Shaped slats support, then screw the ends of the slats to the slats support by using
Screw (3), as shown in Diagram III.
4. Place the Platform Panels (F) on the top of the Slats (D), then tighten the Platform Panels (F) with Slats (D) by
using Screw (4), as shown in Diagram IV.
5. Push the Trundle (D) into the Daybed frame, making sure the Trundle (D) front panel is flush with the Daybed Front
Pane; l (B).

CARE INSTRUCTIONS

1.Spot clean only with a soft, damp cloth.
All manuals and user guides at all-guides.com
THALIA TRUNDLE DAYBED TWIN - ASSEMBLY INSTRUCTIONS
NO.
1
2
3
4
then tighten all bolts with Allen Key (1),

DESCRIPTION

ITEM
Allen Key (0.5cm Dia)
Allen Head Bolt (0.8cm Dia*3.2cm)
Screw (4cm)
Screw (3cm)
as shown in Diagram II.
1 of 2
QTY
1 pc
4 pcs
8 pcs
16 pcs
