INDEX 1. Safety notices and warnings 1.1 Safety operation and Preventive action 1.2 Safety operation and Preventive action Safety operation and Preventive action 1.3 Instruction(application ,working principle, technical parameters) 1.4 Equipment installation Equipment installation 2. Operation 2.3 Reservation 2.4 Running 2.5 Timing 2.6 Operation Stop 3 Sterilization function...
Page 3
5.3 Export data 5.4 Interface description 5.5 key description 6. Parameter set 6.2 System set 6.3 Concentration & Humidity 6.4 Other set 6.5 User management 7. Alarm and security features 7.1 Routine using and maintenance 7.2 Optional using 8. Trouble shooting 8.1 Specification 8.2 Packing List...
Notices Ø In order to ensure safety to use this equipment, please read this manual carefully Ø Make sure put this manual in convenient place for later use Ø Our company doesn’t provide a safe guarantee if not use according to the instruction manual Ø...
Page 5
power supply symbol cut off power supply symbol warning, notice, caution and danger symbol 1.1 Safety operation and Preventive action Don’t place this equipment outdoors. if wet it in the rain, it will cause creepage and electric shock. Only professional person have qualification to install this equipment. If not,It will cause electric shock or fire.
Page 6
Don’t open exterior door when on the process of sterilization ,or it will hurt operator 1.2 Safety operation and Preventive action Don’t touch any electric components or switch in wet hand ,or it will cause electric shock make sure not to suck any drug and airborne particle around the equipment when maintaining ,or it will be harmful for your health Don’t let water splash the equipment ,or it will cause electric shock or short circuit Don’t put container which is full of water on the top of equipment ,or it will cause creepage or...
Safety operation and Preventive action equipment scrap disposal should be done by relevant person .ought to dismount door in case cause stifling Don’t put packing plastic bag in the place children can get ,or it will cause stifling please clean the dust on the power plug and then insert it into power socket tightly .or it will cause heating or strike sparks.
Page 8
The equipment is an air jacket type heating, the principle is through the carbon fiber heating wire all over the outer wall of the box air jacket direct heating inside the box, also called six side direct heating Technical parameters Main technical index BCAJ-201 BCAJ-202 Model argument Temperature control range RT+5℃~60℃...
Page 9
1.Power supply box 2.power switch 3.485 interface 4.Control panel 5.Water inlet 6.shelves 7.water outlet 8.overflow 9.Door seal magnetic strip 10. test hole 11.Weather bar 12.Glass door hook 13.Glass door 1.4 Equipment installation Installation site For proper operation and optimal performance, install the equipment in a location that meets the following conditions: Note: Ambient temperature 10~30℃;...
the device not working properly. The device must be at least 10CM away from the wall. ■ A location away from heat. Avoid installing equipment near heat sources such as boilers or heaters. Excessive heat from the outside will affect the normal operation and control performance of the equipment. ■...
5. Before move equipment Before moving the equipment, if there are items on the carrier bracket in the box, they should be removed to prevent it from slipping. Preparation before operation Before starting the device for the first time, please follow the following procedures: 1.
[Stop] Click the pop-up dialog box to make the system stop; [Catalogue] Click to enter the directory interface; [Curve] Click to enter the real-time curve interface; In the running stop state, click on the sterilization setting key, will [Sterilization set] enter the sterilization setting interface;...
2.4 Running When the system time reaches the reservation setting time, the system enters the [running] state from the [reservation waiting] state, or the user does not set the reservation time, then click the [running] key system to enter the [running] state directly. At this time, the system will be selected; A user can set [select] in the [parameter set]->[time parameter] interface, as shown in the following figure: - Start time: the system directly skipped the [running] state, directly into the [in] state;...
2.6 Operation Stop After the running time is over, the system closes all outputs and enters the stop state; 3 Sterilization function Users can choose sterilization methods in [system set]->[ temperature & sterilization parameters]. There are three sterilization methods: ultraviolet sterilization, humid heat sterilization and high temperature sterilization.
3.4 Alarm function When an alarm occurs in the system, the buzzer calls and prompts, and the [alarm] button surface in the monitoring interface is red flashing. Click to enter the alarm list interface to view the latest 20 alarm contents, as shown in figure: 3.5 Temperature alarm Temperature alarm includes [main temperature overflow ][ door temperature overflow ][ main...
3.6 concentration alarm Concentration alarms include three types of [concentration overflow ][ over concentration ][ under concentration], as follows: Alarm Alarm type Description When the temperature of the main temperature sensor fails, the main Main temperature temperature overflow alarm is generated, the system stops running, and the overflow buzzer calls (click on any interface to mute);...
Communication alarm The communication between the current computer and the touch screen is blocked for more than 20 seconds, and there is a communication fault alarm 3.8 Real-time curves The user can click on [curve] or slide the screen to the left to enter the [real-time curve] interface. In the real-time curve interface, the temperature and speed curves can be viewed in the last 2 hours.
4.1 Mode selection There are two ways to enter the mode setting interface :1, in the monitoring interface click on the set value to enter the mode setting interface quickly ;2, in the [menu interface] click on the "mode setting" to enter the mode setting interface;...
Click run, step time start timing, step time to set time, jump to the next set Running time value to continue running, step time to start the timing again, if the last paragraph, the operation stops; Click on the operation, the system controls the temperature and Not0 concentration, after reaching the constant temperature timing range, the Constant...
Page 20
Paragraph 01 1.30(1 hour 30 minutes) 25.0℃ 10.0% Paragraph 02 1:00(1 hour and 0 minutes) 35.0℃ 12.0% Action flow as follows- determine [user set] [time parameters] timing mode selection [constant temperature]; in [monitor interface] click on the set value to enter the [mode set] interface (when the current running mode is program mode, Go directly to the program mode setting interface;...
5 History data 5.1 Interface description The user enters the [history data] interface, can view the system automatically saved temperature measurement, set value, concentration measurement, set value, humidity measurement value and running, alarm state of historical data, save interval can be set; 5.2 Key Description Content Description...
Page 22
5.4 Interface description In the history curve interface, the user can view the trend of the historical data curve for a period of time, which corresponds to the data stored in the history data. 5.5 key description Content Description [Return] Key Click to return to the directory interface [Historical Data] button Click to enter the History Data interface...
Page 23
6. Parameter set Under the permission of the administrator and the tester, you can enter the[parameter setting] through the [menu interface]. Temperature & concentration Time parameters Initial value (set Name Function range) Year, month, day, hour, minute When the current time is less than that time, the system enters the reservation waiting state until the current time is greater 1 December Booking time...
Page 24
Constant temperature Within this parameter, the system enters the "timing" state from (0~10.0℃) timing the "running" state and starts the timing. Deviation (Temp Bias) End of operation Buzzing prompt time after running. Prompt time (0~300 s)60 Note :0 means continuous call. (Time-SPK) After the lighting is turned on, the lighting time is automatically Lighting time...
Page 25
6.2 System set Enter [system set], you need to enter password 9 to enter, otherwise pop up error prompt dialog box; Temperature & Sterilization Initial value (set Name Function range) sterilization ratioP Time ratio regulation. (0.1~50.0) 10.0 sterilization integral I Integral action regulation. (1~2000 s)300 Differential D of Differential action regulation.
Page 26
1: UV sterilization ;2: Wet heat sterilization ;3: High Method of sterilization UV sterilization temperature sterilization High temperature The sterilization method is the setting value of Sterilization (0.0~200.0℃) sterilization temperature during high temperature temperature 140.0 sterilization (Temp-Ste) When the sterilization mode is high temperature sterilization, when the output of high temperature High temperature sterilization is 0, the output of sterilization is the main...
Page 27
When the temperature measurement value reaches the set value (SP-0.3℃≤PV≤SP+0.3℃) and lasts for 5 Fan opening time minutes, the fan can be set to open or close (20~600s)60 (Fan-Open) intermittently. In seconds. Go beyond this range and continue Wind time Work with fan opening time, when this value is set to 0, (0~600s)0 (Fan-Close)
Page 28
Humidity display: do not display humidity measurements at the monitoring interface; Humidity display Closed Humidity display: display humidity measurement value in monitoring interface; Printer model Type of printer used Ribbon printer Language display Display in Chinese or English Chinese Display Open door fan Is the fan closed when the door opens Open...
Page 29
7. Alarm and security features - Temperature sensor fault alarm: The screen displays: -- words, indicating that the temperature sensor or controller itself is faulty. -Temperature upper limit alarm: When the measuring temperature exceeds the set temperature by 1 degree, the heating will stop working, and the instrument alarm lamp will light up and the alarm sound will ring continuously.
Page 30
7.2 Optional using RS-232/RS-485 instructions for use of the converter - In order to proceed with data communication between the different standard serial interface to the computer, an external device or smart instrument, must provide conversion of standard serial interface. The converter is compatible with RS-232, RS-485 standard, capable of converting single-ended RS-232 signal to a balanced differential RS-485 signals.(it can connect 16 controller of this series together at the same time)
Page 31
8.1 Specification Name CO2 Incubator Air Jacketed Model BCAJ-201 BCAJ-202 Exterior Dimension 755×550×547 905×610×687 (H * W * D) Interior Dimension 500×400×400 650×460×540 (H * W * D) Effective volume 160L Input power 500W 650W Shell Cold-roll steel sheets with powder coat treatment...
Page 32
8.2 Packing List Name Quantity Note Finish product instruction manual Certificate of conformity 80L/2pieces 、 shelf 160L/3pieces Feed water tray www.biolabscientific.com...
Page 33
Gas pipe 2 meters Charging pipe Power cord 300mm long water pipe water tank 10 relief valve Biolab Scientific Ltd. 3660 Midland Avenue, Suite 300, Toronto, Ontario M1V 0B8, Canada Email: info@biolabscientific.com | Website: www.biolabscientific.com...
