Summary of Contents for BioLAB BCLT-2201
- Page 1 Operation Manual BCLT-2201 Low Temperature Circulator www.biolabscientific.com...
- Page 2 Low Temperature Circulator Security tips The matters contained here are extremely important and must be adhered to www.biolabscientific.com...
-
Page 3: Table Of Contents
Low Temperature Circulator Index I.Safety warning…………………................…...4 II. Product........................5 introduction…………………………………………………………………………………….5 1.Outline.........................5 2.Structure Functional Overview..................5 III. Product use…………………………………………………………………....……..6 1. Preparation before use....................6 2. Power on........................6 3. Operating steps......................7 4. Upper deviation alarm setting..................7 5. Check the temperature control accuracy..............7 6. Methods to improve temperature control accuracy.............8 7. -
Page 4: I.safety Warning
Low Temperature Circulator 01Safety warning ! Dangerous (may result in serious loss of property or casualties) 1. The instrument must be grounded and away from sources of electromagnetic interference (must not be zero line or middle line for the ground). 2. -
Page 5: Product
Low Temperature Circulator 02 Product introduction 1. Outline Power plug Switch In and out of monitor the liquid port 2. Structure Functional Overview Circulation tank by the cycle controller, box and refrigeration system composed of three parts. Circulation controller is composed of the temperature controller, temperature sensors, and circulation pump. -
Page 6: Product Use
Low Temperature Circulator 03 Product use 1. Preparation before use 1.1 The product should work under the following conditions of use. ℃ ℃ a. Ambient temperature: 5 ~ 35 ; air relative humidity: ≤ 85% b. Atmospheric pressure: (86 ~ 106) KPa c. -
Page 7: Operating Steps
Low Temperature Circulator 8）Pump running light: Bright when pump running; 2.1.2 Key Description ① Function key: Used for setting value modification; parameter recall and parameter modification confirmation; ② Shift key: used to set value, shift of internal parameters and view of ambient temperature；... -
Page 8: Methods To Improve Temperature Control Accuracy
Low Temperature Circulator 5.2 Choose a point within the range of product control, when the temperature measurement value is equal to the set value, then keep the temperature for about 1 hour. Observe that the difference between the actual measured value of the mercury thermometer and the measured ℃... -
Page 9: Attachment
9. After use, turn off the power switch, unplug the power cord plug, drain into the drain plug (note the bath temperature, be careful to avoid frostbite) and dry the cabinet. 05 Attachment 1. Main Specifications Product Name Cooling / Heating recirculating chiller Model BCLT-2201 Storage tank maximum capacity（L) ～80℃ ﹣ Temperature range 20℃ Temperature accuracy ±0.5℃... -
Page 10: Each Function Parameter Table
Low Temperature Circulator Pump power Pump flow max.（L/min） Maximum head（m） Inlet/Outlet pipe diameter (mm) φ10 Weight (Kg) Liquid storage Noise level ≤45 Dimensions W*D*H (mm) (include 210*410*511 caster) 2. Each function parameter table ） Long press the function key, when the LCD display LK, enter the password, click the function key to enter the setting: A Menu Sheet 2 Factor... -
Page 11: Packing List
Low Temperature Circulator needed. Full point When the controller zero error is -1000 adjust(interce small, large full-scale error, you can ～1000 adjust the value. ） Long press the function key, when the LCD display LK, enter the password, click the function key to enter the setting. - Page 12 Low Temperature Circulator Email: contact@biolabscientific.com Website: www.biolabscientific.com www.biolabscientific.com...
