Wall Plate HDMI® over Cat 5e/6
Extender - 165ft (50m)
ST121HDWP
DE: Bedienungsanleitung - de.startech.com
FR: Guide de l'utilisateur - fr.startech.com
ES: Guía del usuario - es.startech.com
IT: Guida per l'uso - it.startech.com
NL: Gebruiksaanwijzing - nl.startech.com
PT: Guia do usuário - pt.startech.com
For the most up-to-date information, please visit: www.startech.com
Manual Revision: 05/07/2015
*actual product may vary from photos
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for StarTech.com STCST121HDWP
Summary of Contents for StarTech.com STCST121HDWP
- Page 1 DE: Bedienungsanleitung - de.startech.com FR: Guide de l'utilisateur - fr.startech.com ES: Guía del usuario - es.startech.com IT: Guida per l'uso - it.startech.com NL: Gebruiksaanwijzing - nl.startech.com PT: Guia do usuário - pt.startech.com For the most up-to-date information, please visit: www.startech.com Manual Revision: 05/07/2015...
- Page 2 StarTech.com. Where they occur these references are for illustrative purposes only and do not represent an endorsement of a product or service by StarTech.com, or an endorsement of the product(s) to which this manual applies by the third-party company in question. Regardless of any direct acknowledgement elsewhere in the body of this document, StarTech.com hereby...
-
Page 3: Table Of Contents
Table of Contents Product Diagram ..................1 Front View – Transmitter/Receiver Unit ..................... 1 Rear View – Transmitter/Receiver Unit ....................1 Introduction ....................2 Packaging Contents ..........................2 System Requirements ..........................2 Preparing Your Site ................2 Hardware Installation ................3 EDID Configuration ................4 Automatic EDID Configuration ...................... -
Page 4: Product Diagram
Product Diagram Front View – Transmitter/Receiver Unit Transmitter Unit Receiver Unit Status (Power) LED HDMI out Port HDMI in Port Power Adapter Port Power Adapter Port EDID Copy Rear View – Transmitter/Receiver Unit Transmitter Unit Receiver Unit Terminal Terminal Block Power Block Power Link Out 1 (RJ-45 Link Out 1 (RJ-45... -
Page 5: Introduction
Introduction Packaging Contents • 1 x Wall-mounted HDMI Extender • 1 x Wall-mounted HDMI Receiver • 1 x Power Adapter • 1 x Instruction Manual System Requirements • HDMI-enabled video source device (i.e. computer, Blu-ray player) • HDMI-enabled display device (i.e. television, projector) •... -
Page 6: Hardware Installation
Hardware Installation 1. Install the RJ45 terminated Cat5e/6 Ethernet cables to the transmitter and receiver units. a) Connect two RJ45 terminated Cat5e/6 Ethernet cables (not included) to the transmitter unit - one cable for the Link Out 1 RJ45 connector and another one for the Link Out 2 RJ45 connector. -
Page 7: Edid Configuration
3. Install the transmitter and receiver units into the electrical boxes. a) Install the transmitter unit into the electrical box. Please follow the instructions included with your electrical box to determine which mounting points on the transmitter unit should be used. b) Install the receiver unit into the electrical box. -
Page 8: Restore Edid To Factory Default Settings
Note: If the LED flashes RED it is indicated the EDID copy procedure has failed. As a result of one of the following: • The display is not properly connected. • The display is not powered on. • The display does not support EDID. Please check your setup and attempt the EDID Configuration procedure again. -
Page 9: Specifications
Specifications Local Unit Connectors 1x HDMI (19 pin) Female / 2x RJ-45 Female Remote Unit Connectors 1x HDMI (19 pin) Female / 2x RJ-45 Female Maximum Data Transfer Rate HDMI - 3.4Gbps Max Distance 50 m / 165 ft Maximum Digital Resolutions 1080p @ 60Hz, 48-bit Wide Screen Supported Audio Specifications... -
Page 10: Technical Support
Limitation of Liability In no event shall the liability of StarTech.com Ltd. and StarTech.com USA LLP (or their officers, directors, employees or agents) for any damages (whether direct or indirect, special, punitive, incidental, consequential, or otherwise), loss of profits, loss of business, or any pecuniary loss, arising out of or related to the use of the product exceed the actual price paid for the product. - Page 11 StarTech.com is an ISO 9001 Registered manufacturer of connectivity and technology parts. StarTech.com was founded in 1985 and has operations in the United States, Canada, the United Kingdom and Taiwan servicing a worldwide market.
