Wipe protection
The cooktop sensors can be locked for
20 seconds, e.g. to remove soiling. The
sensor is not locked.
Activating
Touch the sensor.
Touch the sensor.
The time counts down in the timer
display.
Deactivating
Touch the sensor until the timer
display goes out.
Demonstration mode
These functions enable the cooktop to
be demonstrated in showrooms without
heating up.
Activating/Deactivating the
demonstration mode
When this mode is set, the cooktop
can be operated as normal.
Switch the cooktop on.
Place an induction-compatible pan on
the cooktop.
Press the 0 and 2 sensors on the
numerical display at the same time for
6 seconds.
In the timer display, flashes
alternately with (demonstration
mode activated) or (demonstration
mode deactivated) for a few seconds.
Additional functions
Displaying cooktop data
The model designation and software
version can be displayed.
Model number/Serial number
Switch the cooktop on.
Place an induction-compatible pan on
the cooktop.
Press the 0 and 4 sensors on the
numerical display at the same time.
Numbers will appear in the timer display
one after another, separated by a dash.
Example: (Model number
KM 1234) – (Serial
number)
Software version
Switch the cooktop on.
Place an induction-compatible pan on
the cooktop.
Press the 0 and 3 sensors on the
numerical display at the same time.
Numbers appear in the timer display:
Example: : = Software version 2.00
47
