Surface-Mounted Installation - Miele KMDA 7476 FR Operating And Installation Instructions

Installation

Surface-mounted installation

 Create the worktop cut-out.
Remember to maintain the minimum
safety distances (see "Installation –
Safety distances").
 Seal the cut surfaces of wooden
worktops with a suitable sealant to
avoid swelling caused by moisture.
The sealant must be heat-resistant.
Make sure the sealant does not come
into contact with the top surface of
the worktop.
 Attach the sealing strip provided
underneath the edge of the cooktop.
Do not apply the sealing strip under
tension.
 Feed the mains connection cable for
the cooktop down through the
worktop cut-out.
 Place the cooktop centrally in the cut-
out. When doing this, make sure that
the seal of the appliance sits flush
with the worktop on all sides. This is
important to ensure an effective seal
with the worktop.
Do not use any additional sealant
(e.g. silicone).
If the seal does not meet the worktop
correctly on the corners, the corner
radius (≤ R4) can be carefully scribed
to suit.
 Connect the cooktop to the mains
electricity supply (see "Installation –
Electrical connection").
 Check that the cooktop works.
88
