- Page 1 CENTRO 6417 ™ MULTIFUNCTION CABINET INSTRUCTION MANUAL LET’S GET STARTED. DESIGN MATTHEW WEATHERLY...
- Page 3 Congratulations on the purchase of your Centro Multifunction Cabinet 6417 from BDI. Your multifunction cabinet has been designed to provide a lifetime of enjoyment. This manual will provide you with assembly instructions and other helpful information that will ensure that you get the most out of your product. Please save it for future reference.
- Page 4 HARDWARE AND COMPONENTS Unpack and identify the parts listed below. The assembly workspace should be a non-marring surface such as carpet. For missing hardware pieces, please contact BDI Customer Service at customerservice@bdiusa.com. Do not use power tools for the assembly of this product.
- Page 5 HARDWARE AND COMPONENTS PART # PART # DESCRIPTION Base DESCRIPTION Small File Bar QUANTITY QUANTITY PART # PART # DESCRIPTION DESCRIPTION Large File Bar File Bar Clip QUANTITY QUANTITY NEED ASSISTANCE? customerservice@bdiusa.com BDIUSA.COM | 5...
- Page 6 ASSEMBLY STEP 1. ATTACH THE BASE Carefully position (A1) Cabinet onto its back. Attach PART/DESCRIPTION both (C3) Base to (A1) Cabinet using (H1) Screws and tighten with (T1) Hex Wrench. T1-HEX WRENCH H1-SCREW 6 | BDIUSA.COM CENTRO 6417...
- Page 7 STEP 2. INSTALL BUMPERS & PLACE GLASS PANEL ASSEMBLY Carefully position Cabinet onto its base. Remove PART/DESCRIPTION paper backer from (H3) Bumpers and adhere to cabinet as shown. H3-BUMPER Place (C1) Glass Panel onto the (A1) Cabinet. The edge of (C1) Glass Panel should be inset 1/16" (1.5mm) from the edge of the (A1) Cabinet.
- Page 8 ASSEMBLY STEP 3. ATTACH THE PULLS Open one drawer at a time and attach (C2) Pulls to PART/DESCRIPTION (A1) Cabinet using (H2) Screws and tighten with a Phillips Screwdriver. H2-SCREW NOT INCLUDED Phillips Screwdriver 8 | BDIUSA.COM CENTRO 6417...
-
Page 9: Fine Tuning
ARRANGING YOUR FILES FINE TUNING For forward facing files, attach (C6) File Bar Clips PART/DESCRIPTION to each end of the (C4) Small File Bars. Slide the bars onto the rails so that the (C6) File Bar Clip goes into the groove. C4-SMALL FILE BAR For sideways facing files, see below. -
Page 10: Care And Maintenance
While BDI’s stained wood finishes are stable in tone & appearance, all finishes are subject to some degree of discoloration with prolonged exposure to direct sunlight. Please take care to avoid positioning your BDI cabinet in any area with extensive direct sunlight. -
Page 11: Warranty
Select chairs carry coverage for five (5) years from the date of the product delivery, based on an 8-hour daily use pattern. BDI reserves the right to refine or update its warranty from time to time. See the complete and latest warranty document at www.bdiusa.com/warranty. - Page 12 These distinctive product configu ations are protected by US and international patents, trade dress, and/or copyright laws. Centro & BDI are trademarks of Becker Designed, Inc. All rights reserved. ©2021, BDI | V.03.18.2021 Made in China.
