BDI CENTRO Assembly Instructions

Multifunction cabinet
Hide thumbs Also See for CENTRO:
1
2
3
4

Advertisement

Quick Links

Download this manual See also: Owner's Manual
CENTRO
MULTIFUNCTION CABINET
Product Registration
Registering your new BDI product allows us to send you important
product updates, service information and helpful hints related to your
BDI products. Register today, and you will be entered to win free a BINK
table from BDI. www.bdiusa.com/product-registration/
Placement and Maintenance
Centro ™ Office furniture is designed for indoor use on level floors. Clean
glass with glass cleaner, and steel parts and wood veneer with a moist
cloth.
Your Centro ™ Office furniture is engineered for easy assembly. Carefully
follow this procedure to prevent any damage.
Do not use power tools for assembly of this product.
Step 1
Unpack and identify the parts listed below. The assembly workspace
should be a non-marring surface such as carpet. For missing hardware
pieces, please contact BDI Customer Service at customerservice@
bdiusa.com. For all other concerns, please contact your BDI retailer.
Designed by Matthew Weatherly.
These distinctive product configurations are protected by US and international patents, trade dress, and/or
copyright laws. Centro & BDI are trademarks of Becker Designed, Inc. All rights reserved. ©2015, BDI
Made in China. 02.16.2016 V2
6417
TM
C1 Glass Panel x 1
A1 Cabinet x 1
C3 Base x 2
bdiusa.com
customerservice@bdiusa.com
T1 4mm Hex Wrench
H1 1/4-20 x 15mm
Screw x 16
H2 M4 x 37mm
Screw x 6
H3 1/4-20 x 19mm
Screw x 3
H4 Bumper x 2
C2 Pull x 3
C4 Small File Bar x 2
C5 Large File Bar x 1
C6 File Bar Clip x 4
Tool Required:
Phillips screwdriver
