INSTALLATION INSTRUCTIONS
Product Registration
Registering your new BDI product allows us to send you important
product updates, service information and helpful hints related to your BDI
products. Register today, and you will be entered to win free a BINK table
from BDI: www.bdiusa.com/register
Maintenance
Clean wood veneer with a moist cloth.
Your Centro Office furniture is engineered for easy assembly. Carefully
follow this procedure to prevent any damage. Do not use power tools for
assembly of this product.
Step 1
Unpack and identify the parts listed below. The assembly workspace
should be a non-marring surface such as carpet. For missing hardware,
please contact BDI Customer Service at: customerservice@bdiusa.com.
For all other concerns, please contact your BDI retailer.
C10L Mounting Block
Designed by Matthew Weatherly.
These distinctive product configurations are protected by US and international patents, trade dress, and/or
copyright laws. Sequel & BDI are trademarks of Becker Designed, Inc. All rights reserved. ©2016, BDI
Made in Taiwan. 06.09.2016 v2
CENTRO
6459
™
DRAWER FOR 6459
C11 Drawer Liner
A2 Drawer
bdiusa.com
customerservice@bdiusa.com
C10R Mounting Block
T2 4mm Hex Wrench
H10 1/4-20 X 58mm Screw x 4
Advertisement
Table of Contents
Related Manuals for BDI CENTRO
Summary of Contents for BDI CENTRO
- Page 1 C10R Mounting Block Designed by Matthew Weatherly. These distinctive product configurations are protected by US and international patents, trade dress, and/or copyright laws. Sequel & BDI are trademarks of Becker Designed, Inc. All rights reserved. ©2016, BDI Made in Taiwan. 06.09.2016 v2...
- Page 2 Drawer Assembly Option #1 Attach the Drawer Body A2 by inserting 4 Screws H10 through the holes on Mounting Blocks C10L and C10R and thread them into the 4 inserts on the bottom of your Centro Desk 6452. H10 x 4 bdiusa.com...
- Page 3 A2 under the desk. The other person inserts Screws H10 into the holes in the side mounting blocks and threads them into the inserts under the desk. Start all 4 screws before fully tightening. 2 Person Task H10 x 4 bdiusa.com CENTRO 6459 customerservice@bdiusa.com DRAWER FOR 6459...
- Page 4 Install the drawer liner Install the Drawer Liner C11 into the Drawer A2 as shown. C11 Drawer Liner A2 Drawer bdiusa.com CENTRO 6459 customerservice@bdiusa.com DRAWER FOR 6459...
