CENTRO
MOBILE FILE PEDESTAL
Product Registration
Registering your new BDI product allows us to send you important
product updates, service information and helpful hints related to your
BDI products. Register today and you will be entered to win free a BINK
table from BDI. www.bdiusa.com/product-registration/
Placement and Maintenance
Centro ™ Office furniture is designed for indoor use on level floors. Clean
glass with glass cleaner, and steel parts and wood veneer with a moist
cloth.
Your Centro ™ Office furniture is engineered for easy assembly. Carefully
follow this procedure to prevent any damage.
Do not use power tools for assembly of this product.
Step 1
Unpack and identify the parts listed below. The assembly workspace
should be a non-marring surface such as carpet. For missing hardware
pieces, please contact BDI Customer Service at customerservice@
bdiusa.com. For all other concerns, please contact your BDI retailer.
Designed by Matthew Weatherly.
These distinctive product configurations are protected by US and international patents, trade dress, and/or
copyright laws. Centro & BDI are trademarks of Becker Designed, Inc. All rights reserved. ©2015, BDI
Made in China. 02.11.2016 V2
6407
TM
A1 Cabinet
bdiusa.com
customerservice@bdiusa.com
H2.1 M4 x 22mm
Screw x 2
H2 M4 x 37mm
Screw x 2
H5 Phillips Machine
Screw x 20
C2 Pull x 2
C4 Small File Bar x 1
C6 File Bar Clip x 2
C8 Locking Swivel
Caster x 4
C9 Fixed Caster x 1
Tool Required:
Phillips screwdriver
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for BDI CENTRO 6407 SW
Summary of Contents for BDI CENTRO 6407 SW
- Page 1 Phillips screwdriver Designed by Matthew Weatherly. These distinctive product configurations are protected by US and international patents, trade dress, and/or copyright laws. Centro & BDI are trademarks of Becker Designed, Inc. All rights reserved. ©2015, BDI Made in China. 02.11.2016 V2...
- Page 2 Step 2 - Lay Cabinet on its back side. Attach Casters to Cabinet using Screws H5 and tighten with a Phillips screwdriver. Step 3 - Attach Pulls to top drawer using Screws H2.1, attach Pulls to bottom drawer using Screws H2 and tighten with Phillips screwdriver.
- Page 3 Step 4 - File Bar Installation (Letter File) For letter files facing sideways, attach File Bar Clip C6 to both ends of Small File Bar C4 as shown. Place the file bar assembly in the notches located on the left and right drawer side panels. For front facing letter files, skip this step altogether.
