4500 Series Power Operator
Model 4540, Push & Pull Mounting
Installation Instructions
WARNING
This product can expose you to lead which is known to the
state of California to cause cancer and birth defects or other
reproductive harm.
For more information go to: www.P65warnings.ca.gov.
Up to 90° opening
Operator Components
4500LAP
Operator Body
4501MP
Mounting Plate
Tools Needed
Copyright © 2024, 2025, ASSA ABLOY Accessories and Door Controls Group, Inc. All rights reserved. Reproduction in whole or
in part without the express written permission of ASSA ABLOY Accessories and Door Controls Group, Inc. is prohibited.
80-9345-0001-020 Rev 2 01/25
Push Side
Includes: Power Supply,
Door Cord, Door Cord Clip,
4501COV
Includes: Cover and
Cover Locking Bracket
NOTES:
y 2019S Spacer Block (included) required for stops less than 2".
y Cover locking bracket (included) and door cord clip (included)
available for purchase separately. (P/N 4501PCK)
Safety #2 Punch 25/64"
Glasses
Approved 2025-01-06
Pour la version francaise voir NortonRixson.com.
READ AND FOLLOW ALL INSTRUCTIONS.
SAVE THESE INSTRUCTIONS.
4501PS
& End Link
4501-1
Includes: Arm Assembly,
Soffit Plate, & 2019S Spacer Block
3/8" 7/64"
Adjustable
Pull Side
Up to 90° opening
Accessory Components
Wave-to-Open Kit
Square Push Button Kit
Supplied Tools
7/16" or 3/16" 5/32"
Wrench
WTO
OR
SQPB
9/64" Rivet Nut
Install Tool
