Loading the Dishwasher

Before placing the dishes in the dishwasher, remove larger food
particles to prevent the filter from becoming clogged, which re-
sults in reduced performance.
If the pots and pans have baked-on food that is extremely hard to
remove, we recommend that they are soaked before washed. This
will eliminate the need for extra wash cycles.
Pull out the rack to load the dishwasher.
How to use the lower rack
We recommend that you place the most difficult to clean items on
the bottom rack: pots, pans, lids, serving dishes and bowls, as
shown in the figure to the right.
It is preferable to place serving dishes and lids on the sides of the
racks in order to avoid blocking the rotation of the top spray arm.
- Pots, serving bowls, etc. must always be placed face down.
- Deep pots should be slanted to allow the water to flow out.
- The lower rack features fold down tine rows (see fig.A) so that
larger or more pots and pans can be loaded.
- The basket can be doubled (see fig.B) so that only one section
may be used when the silverware load is light. This also makes
space for additional pots and pans and it can also be placed in
the upper rack.
- Silverware should be placed in the silverware basket with the
handles at the bottom; if the rack has side baskets, the spoons
should be located individually into the appropriate slots. Espe-
cially long utensils should be placed in the horizontal position at
the front of the upper rack.
How to use the upper rack
The upper rack is designed to hold more delicate and lighter
dishware, such as glasses, cups and saucers, plates, small bowls
and shallow pans (as long as they are not too dirty).
- Position the dishes and cookware so that they do not get moved
by the spray of water.
The upper rack can be adjusted for height by using the knobs lo-
cated on both sides of the rack itself (see fig.C).
Adjust the upper basket to the higher level and you have more
space to accommodate those taller pans and trays in the bottom
Lean tall glasses and those with long stems against the shelf-not
against other items to be washed.
Place glasses, cups and small bowls on the additional cup rack.
The additional cup rack can be swivelled in or out as required(see
Knife rack
The knife rack clips onto the side of the top basket, giving you the
freedom to wash your large sharp knives separately and out of
harm's way (see fig.E).
Lower Rack
Upper Rack
Load for 12 Standard Settings (for IEC-EN 50242 tests)

Starting the Appliance

Starting a wash cycle
After having completed all of the installation steps in the pre-
ceding paragraphs, turn on the water to the unit, partially open
the door of the dishwasher, and press the ON-OFF button "A"
located on the control panel. The "B" indicator light will come
on. At this point, the appliance is on and ready to be
Setting and Starting a wash Cycle
Choose the desired cycle by pressing the cycle selection but-
ton "G". Each time it is pressed, one of the cycle indicator lights
"F" will begin to blink in succession.
Choose the wash cycle you feel is most appropriate for the type
of dishes that need washing (consult the wash cycle table con-
tained in this manual, especially when first using the appliance).
Close the door and then the wash cycle has begun and cannot
be modified. If necessary, read the paragraph entitled, "Can-
celling or modifying a cycle while underway. "The end of the
cycle will be signalled by six acoustic sound, and the indicator
light "F" will turn off.
Cancelling or modifying a cycle while underway
Premise: A cycle that is underway can only be modified if it has
only been running for a short time.
Otherwise, the detergent may have already been used, and the
appliance may have already drained the wash water. If this is
the case, the detergent dispenser must be refilled (see the para-
graph entitled, "Loading the Detergent").
To change the cycle currently underway, open the door and
press the ON-OFF button "A",follow the instructions contained
in the paragraph entitled, "Starting a wash cycle ","Setting and
Starting a Wash Cycle".
To set a new wash cycle, follow the instructions contained in
the paragraph entitled, "Setting and Starting a Wash Cycle".
If you forget to load some of the dishes...
The wash cycle can be interrupted by opening the door care-
fully (in order to avoid being sprayed by hot water). When the
door is closed again, after 30 seconds the cycle will automati-
cally restart at the point where it left off.
At the end of the wash cycle
The end of the cycle will be indicated by six acoustical signal,at
the same time the "F" indicator light will turn off. Open the door,
turn off the appliance using the ON-OFF switch and turn off the
water supply to the unit. Wait a few minutes before removing the
dishes so as to avoid handling them while still hot (when they
are more susceptible to breakage) and to get better drying results.
Setting The Start Delay Time
Open the door of the dishwasher partially. If the "J" button is
pressed (see, Close-up View" Control Panel"). The start time for
the wash cycle can be delayed for 2,4,6,8,10 or 12 hours.
Each time the button is pressed, the "I" light will blink indicating
the length of the delay.
After selecting the delay time, the wash cycle can be set, as
explained in "Starting a wash cycle..." , close the door and at this
point the delay period will begin to count down. During this pe-
riod the delay indicator light (I) will come on. At the end of the
delay time, the indicator will turn off and the cycle will start.
a) During the delay period, none of the settings can be modified.
If necessary, they can be cancelled by pressing press the ON-
OFF button "A" located on the control panel.
b) If the door is opened during the delay period, the clock will
stop the countdown. It will start again when the door has been
Wash Cycle Adjustment Buttons
1/2 Load Button
This button (see" Close-up View-Control Panel", letter "C") makes
it possible to wash dishes using only the upper rack if there are
not enough dishes for a full load, This will allow you to save on
water and electrical energy.
