Question 1
The stud spacing is greater than what the TV wall mount was
designed for or you can not center the TV wall mount in your desired location.
• Hardwood size: Thickness: about 2" (51mm), Width: about 4" (102mm). The
hardwoods must be capable of holding the weight of the TV plus the TV wall
mount.
Answer
• Self-supplied Lag Screws: 1/2 x 4"
Step 1 Apply the hardwoods (can be bought in
any lumberyard) to Create A Center between
your wood studs. Then screw your hardwoods on
your wall.
FAQs
Lag screws (Provided in the hardware
bag)
Step 2 Fix the TV wall mount on the
hardwoods.
01
Advertisement
Related Manuals for Perlesmith PSMTK1
Summary of Contents for Perlesmith PSMTK1
- Page 1 FAQs Question 1 The stud spacing is greater than what the TV wall mount was designed for or you can not center the TV wall mount in your desired location. • Hardwood size: Thickness: about 2” (51mm), Width: about 4” (102mm). The hardwoods must be capable of holding the weight of the TV plus the TV wall mount.
- Page 2 Question 2 How to raise / lower the TV if the TV wall mount is fixed on wall? Answer: Step 1 Remove the TV from the TV wall mount. Step 2 Remove the TV brackets on the TV. (For lifting up the TV, follow the instruction of ①. For lowering the TV, follow the instruction of ②).
- Page 3 Question 1 L'espacement est plus important que le cadre mural de la TV, ou le centre du cadre mural de la TV ne va pas à l'endroit souhaité. • Taille des bois durs : épaisseur : environ 51mm (2 po), profondeur : environ 102mm (4 po).
- Page 4 Question 2 Comment lever / baisser la TV si le cadre est fixé au mur? Réponse : Etape 1 Retirer la TV du cadre de la TV. Etape 2 Retirer les équerres de la TV de la TV. (Pour lever, suivre les instructions ①. Pour baisser, suivre les instructions ②).
