HSA6500 GSM alarm
Installation · Programming · Operating
Keep this manual safe for reference and future maintenance
Introduction
Thank you for choosing the Yale Wireless Alarm System.
This simple to install system has been designed with the
user in mind.
All the components are self contained and no connections
are needed between the units. There is no need to
damage the home decor, lift carpets or run cables.
You can install up to 20 devices in this system. As well as
extra door/window contacts, PIRs and smoke detectors,
you can add keyfob remote controls and keypads for
added control convenience.
There is no need to wire into the mains supply or seek
the services of a qualified electrician. The control unit is
powered by a plug top supply and all other components
are powered by battery (all batteries included).
Batteries will operate for 2 years or more before they need
changing. Regular testing and battery changes (when
notified by the system) will ensure reliability and peace of
mind.
The security detectors, control panel and external siren
are 'tamper' protected. Any unauthorised tampering with
these items will result in an alarm. This feature can be
turned off by the user when a battery change is required.
Display extreme caution when using ladders or steps,
please follow manufacturer's instructions.
Be careful when using hand and power tools and follow
the manufacturer's guidelines when using them. Take care
that the correct tools are used. Wear goggles or protective
clothing where required.
The external Siren is extremely loud, please ensure you
replace the cover and retreat to a safe distance before
testing.
The dialling/SMS facilities must only be used with persons
who have consented to being contacted by the system.
The system is not to be used to make 999 emergency
calls directly. Yale do not hold responsibility for any actions
taken by emergency services for incorrect use of the
dialling/SMS facility.
Special Notes on Compatibility:
This alarm system is NOT compatible with SmartHome
Alarm and Easy Fit alarm accessories. Please note the
prefix "HSA" on the front of the model number to indicate
compatibility.
Contents
Contents
Recommended Installation Sequence
We recommend you follow the simple install
sequence, headings numbered 1-6.
Information and illustrations are subject to change within this
document. Yale reserves the right to alter the specification and
product design at anytime without notice. Yale® is a registered
trademark. © 2015 ASSA ABLOY. All rights reserved.
2
4
6
8
11
17
20
22
24
27
28
30
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Assa Abloy HSA6610
Summary of Contents for Assa Abloy HSA6610
-
Page 1: Table Of Contents
“HSA” on the front of the model number to indicate Information and illustrations are subject to change within this compatibility. document. Yale reserves the right to alter the specification and product design at anytime without notice. Yale® is a registered trademark. © 2015 ASSA ABLOY. All rights reserved. -
Page 2: Location Planning
Location planning Work out the best places to locate the devices for maximum protection. Having chosen the locations do not mount at this stage. Home and Away Mode Planning Keypad remote control accessory The home arming mode allows the premises to be When used as second keypad, it is ideal in part armed so that no one can get inside without bedrooms or at the top of a stairwell so the... - Page 3 Smoke detector Siren • Mount in the middle of the ceiling at the top of a stairwell, or on the centre of hallway ceilings Choose a position on an external wall where the where smoke would most likely be detected. siren would be most prominent. Mount as high as • Do not mount in corners or above cooking possible, out of easy reach. appliances and heaters.
-
Page 4: Unpack All The Parts
Unpack all the parts Siren Backspace/Return Down WARNING Power LED Text Display The siren is very loud, be prepared! Take care not to Fault LED activate the siren tamper switch unnecessarily. Home Arm 1 The siren comes in two shapes, rectangle or round depending on the kit purchased. - Page 5 Keyfob remote control accessory Door/window contacts 1 Open the battery compartment using a coin by 1 Pull out the battery saver tab on the side to activate turning cover in the direction of the big arrow so Keypad remote control Keyfob remote control accessory the battery.
-
Page 6: First Time Easy Install
First Time Easy Set-up The installation guide will provide you with prompts to easily set-up the system. • Any omissions or mistakes can be rectified 2. Set the phone number to alert later. Once the first time install has been successfully completed it will not be shown again. - Page 7 Error Condition Next, the screen will display: (Upon selecting Exit setup) .Exit setup Repeat Setup If there are no device/accessory (accidentally deleted) in the system and you selected “Exit Setup”, you will be prompt with “Please add at least one device”. Upon selecting “Exit Setup”, you will now be prompted with: mount devices,...
-
Page 8: Mounting Alarm Devices
Post Installation/Mounting Devices Note: Tamper is disabled during initial set-up. For details on disabling tamper see Section 6 Control Unit Mounting dc zone01 b Wall Mounting ..Using the two holes on the mounting back plate, *Note: this screen shot is use as example only. mark the position of the holes. - Page 9 1 Find a location on the door/window where you would like the device to be mounted. The sensor should be on the frame while the magnet should be on the door/window. Once mounted make sure the tamper switch spring is fully depressed. The gap between the magnet and sensor should Wall fixing be no more than 10mm when closed (maybe...
- Page 10 About your alarm system (default settings) All accessories were pre-set to To change the exit and entry timer, see Chapter 5, Adv. Settings. “entry” attributes. To change the property of individual sensor (i.e. Burglar attribute where the individual sensor will When the system is first armed, user will have 30 instantly alarm when triggered), see Chapter 5, seconds to exit the building.
-
Page 11: Control Panel Menu System In Detail
Control Panel Menu System in Detail System Test Entering Programming Mode When System Test is selected, you will be given 4 The programming mode is for you to configure different options: Sensor Test, External Siren (test), the system, and make any changes to the pre-set Panel Siren (test) and Phone alert. - Page 12 If you press any test/learn button on any learnt-in The following devices have a fixed emergency sensor (confirm by pressing 3), these sensors will be zone type: ignored during the Home Arm mode. · Smoke Detector · Remote Controller emergency Button Repeat this step to ignore additional sensors.
- Page 13 3 You are now asked to enter a name. Press 3 to • Siren Tamp. On confirm or P to cancel without naming. • Siren Tamp. Off • Confirm On Device Naming • Confirm Off • Entry Snd On • Each device can be given a 12 character name. •...
- Page 14 1 Select the Log menu and press 3. 2 Select the code you want to change and press 3, enter your new PIN code and press 3. You will 2 The log can now be scrolled up and down and be asked to repeat the PIN code, enter it again viewed with the st keys;...
- Page 15 Alarm Length Tel. Numbers The siren (both external and built-in) will sound when This menu has a list of 6 telephone numbers (notify an alarm is activated. The length of the alarm can be via voice dial or SMS). These numbers are dialled/ set from 1 to 15 minutes in 1 minute increments with SMS in order, a maximum of 20 digits per number this setting.
- Page 16 1 Select Test report and press 3. 2 A list of numbers will be displayed, select the number you want to test and press 3. 3 The control unit will now display test progress. • The test can be cancelled at any time by either pressing the P button or the call recipient pressing “9”...
-
Page 17: Using The System
Using the System Arm and disarm the system and practice using it. Trigger the alarm by arming the system and opening protected door/windows and walking past PIRs. Now is the time to show the rest of the family how simple it is to use. The PIRs have a built-in sleep timer to save 1 Press the disarm key on the keyfob or press the battery power. - Page 18 or away entry are triggered, the alarm will be pre-recorded messages (Burglar, Emergency) activated immediately. depending on the nature of the alarm and finally an acknowledgement request message. • The recipient should acknowledge the message by Stop the Alarm and Alarm pressing ‘9’ on their telephone when prompted. • Recipients using radio DECT phones or mobiles Display should press the numbers repeatedly until the call...
- Page 19 Disabling the system tamper Before mounting it is important to disable the siren and system tamper to avoid the siren sounding an alarm. 1 Press the Menu key and enter a user PIN code followed by 3. 2 The control unit is now in programming mode, Select Devices, then Program Siren and Siren Tamp.
-
Page 20: Adding And Using Accessories
Adding and using Accessories To provide additional protection you can add extra door/window contacts, PIRs, keyfob remote controls, keypad remote controls, help buttons and smoke detectors. These are available separately from your local stockist. Preparation See section 2, for battery insertion or activation and part identification. - Page 21 Using your Help Button Using your keypad • The keypad can be used to Away Arm and Home Arm the system using the buttons as shown. Activate an Alarm • The system is disarmed by pressing the disarm • Press and hold the red button for at least 3 button followed by any user code, similar to using seconds. The LED will light momentarily and the the control unit keypad.
-
Page 22: Changing The Batteries
Changing the Batteries Always use alkaline batteries or the correct type of coin cells as replacements because any other battery can cause problems with the operation of the system. Typical life of batteries is two years or more. Ensure the correct steps are taken when changing batteries in tamper protected devices. - Page 23 Help button battery change When the battery is low the LED will glow dimly Keyfob battery change when the button is pressed. The battery is changed When the battery is low the LED will glow dimly as follows: when any key is pressed. The battery is changed as follows: 1 Loosen the bottom case screw and take button cover off base.
-
Page 24: Troubleshooting
Troubleshooting www.Yale.co.uk For online assistance, please visit: Siren • Check that PIR is not mounted above convector heaters or pointing directly at windows. Siren does not respond to arming or disarming PIR LED flashes • Batteries are low or the tamper switch is disturbed. • Siren batteries are completely exhausted. Check that the tamper switch spring is making Check siren batteries by removing siren cover, if contact with base. - Page 25 Reset to factory default setting _____________________________________________ The control panel can clear all programmed Amber triangle LED illuminates parameters by the following sequence: and warning beeps (every 30 1 Power down control panel and remove the battery. seconds if enabled) 2 Apply power while holding down the p key. • There is a fault condition in your alarm system.
- Page 26 5 Press the P key. 6 All programmed parameters are reset to factory default setting. All learnt sensors will be kept. 7 If more than 17 incorrect keys are entered, then the unit will revert to normal Alarm On mode. _____________________________________________ Jamming/Interference detection User can enable Jamming/interference...
-
Page 27: Sensor Response Table
Alarm sensor response table Disarm Away Arm Home Arm Exit Away Arm Home Arm Entry Entry Burglar No action Instant Instant No action No action No action Burglar alarm Burglar alarm Home Omit No action Instant No action No action No action No action Burglar alarm... -
Page 28: Specifications
Specifications All devices Passive infra red (PIR) Help button Detector Radio Microprocessor controlled Environmental conditions 433.92MHz AM transmitter -10°C to 40°C, relative humidity Alarm processing Microprocessor Power supply CR2032 coin cell. 70% non-condensing for all units controlled dual edge sequential 3 years typical domestic service life except the external siren. - Page 29 EN 300 220-1 / V2.1.1 (2006-04) EN 301 489 -1, / V1.6.1 (2004-12) EN 301 489-3, / V 1.4.1 (2002-08) EN 60 950 / 2001 + A11 + corrigendum 2004 John Ward Director Date: 07/10/14 On behalf of ASSA ABLOY Ltd.
-
Page 30: Remote Sms Control
Remote SMS control Instead of using remote dial-in to control your panel, you can download the Yale GSM control app to SMS your panel with control commands. Downloading the app Go to iOS app store or Google Play to search for “Yale GSM control” phone app. The app will send an SMS controlled message from your phone to your alarm panel. Please check with your mobile provider for SMS cost. Note: This app may not work correctly on certain GSM alarm models. Please use remote Dial-in access instead (see Section 6). - Page 31 PIN Settings You can change your user PIN code or the SMS keyword. Pressing “Save” will trigger an SMS command to be sent to the panel. This is the same as “Adv. Settings” -> “PIN code”, page 14, Note: Please change the panel setting by pressing “Edit”...
- Page 32 Please recycle where THE ASSA ABLOY GROUP is the world’s leading facilities exist. Check with your local manufacturer and supplier of locking solutions, dedicated authority or retailer for recycling advice.
