- Page 1 Proudly Designed and Manufactured in New Zealand( NZS:4301/93) Security Merchants Australia P/L VIC 03 9338 2427 NSW 02 9890 5300 QLD 07 3552 5966 SA 08 8297 5555 WA 08 9240 7500 National Technical Support Contact 1300 655 076 An ASSA ABLOY Group Company...
-
Page 2: Table Of Contents
CONTENTS Page No. INTRODUCTION About your Alarm OPERATING YOUR ALARM General Information Arming the Alarm Disarming the Alarm Arming in Stay Mode Disarming Stay Mode Bypassing Zones Manual Panic, Medical & Fire Alarms Resetting Alarms LCD Keypad Quickview Mode SPECIAL CONTROL BUTTON FUNCTIONS Directly Controlling Outputs from the Keypad Disable Day (Chime) Mode Alarms Operating the Access Control Output... -
Page 3: Introduction
INTRODUCTION ABOUT YOUR ALARM Thank you for choosing to protect your premises with the ‘ series’. In doing so you have invested in the most advanced and adaptable panel on the market. Your ‘S series’ can operate as two totally independent alarms. These independent ‘AREAS’ can be controlled from one global keypad or from multiple keypads assigned to specific areas. -
Page 4: Operating Your Alarm
OPERATING YOUR ALARM GENERAL INFORMATION Your ‘S series’ Alarm Controller has been designed with you the user in mind. Clearly named backlit keys mean you don't have to remember complicated key combinations to achieve normal daily operations. As with everything about the ‘S series’... -
Page 5: Arming In Stay Mode
SELECTIVE AREA DISARMING of THE ALARM If the panel is split into two areas and the user and keypad are both assigned to the two areas it is possible to select which Area or Areas you wish to Disarm. To do this your installer will have programmed the panel to require the <ARM> button to be pressed before the code to arm the panel. -
Page 6: Bypassing Zones
BYPASSING ZONES The Bypass button allows you to temporarily bypass zones of your choice prior to arming your panel. The bypassed zones will revert back to normal the next time you disarm the panel unless it is a 24 hour zone. A bypassed 24 hour zone will remain bypassed until the bypass is manually removed by reversing the procedure shown below. -
Page 7: Lcd Keypad Quickview Mode
LCD KEYPAD QUICKVIEW MODE The LCD keypad will normally show an unsealed zone by displaying its programmable zone name on the keypad. If more than one zone is unsealed at any time the LCD keypad will scroll through the zones sequentially showing each zone name individually. -
Page 8: Special Control Button Functions
SPECIAL CONTROL BUTTON FUNCTIONS The <CONTROL> button on the keypad has a number of uses depending on the options set by your installer. It can be used to disable Chime-zone alarms or directly control any of the outputs from the keypad. The operation of the special <CONTROL>... -
Page 9: Remote Command Control Operation
REMOTE COMMAND CONTROL OPERATION HOW REMOTE COMMAND CONTROL WORKS Another powerful feature available from your alarm is Command Control. This feature is a remote control facility which allows valid users to access the panel via a standard touch tone telephone and check or change the Arm/Disarm status of each of the areas, operate each of the eight outputs, turn on an optional Microphone or force a test call to the Central Station. -
Page 10: Local Command Control Of Outputs
will automatically hang up the line. This 15 second timer is active during the whole command control process so a period of 15 seconds without a key press will cause the panel to hang-up. LOCAL COMMAND CONTROL OF OUTPUTS If a DTMF control code is programmed for output control the same code can be used to locally control output/s from the keypad. -
Page 11: Programming Your Alarm
PROGRAMMING YOUR ALARM GETTING INTO PROGRAM MODE There are 2 levels of program mode, CLIENT mode and INSTALLER mode. Normally the installer will give you access to the CLIENT mode so you can add, delete, or change the user codes. In CLIENT mode you can program up to 100 individual User Codes that may be 1-6 digits in length. -
Page 12: Programming The Time & Date
Any existing number will be displayed at the keypad then press; <NEW TELEPHONE NUMBER> <ENTER> The new number will be displayed at the keypad. At any time you can enter in the address for the telephone number just to view the currently programmed value then press the <PROGRAM>... -
Page 13: Program/Delete/Find Radio Users
<PROGRAM> <175> <ENTER> <15> <ENTER> <####> <ENTER> #### = 1-4 digit code PROGRAMMING/DELETING or FINDING RADIO KEY CODES or ACCESS TAGS The alarm system can have up to 80 radio users programmed. The optional receiver board must be fitted to allow radio users to work. -
Page 14: Hide User Codes
HIDING USER CODES WHEN IN INSTALLER MODE If the User is authorised to do so they may prevent the User codes from being displayed when in Installer Mode. The owner can Hide User Codes from CLIENT program mode. To Hide User Codes press; <PROGRAM>... -
Page 15: User Functions
USER FUNCTIONS STARTING WALKTEST MODE While in CLIENT mode a User with the proper authority can start walk-test mode. This special mode latches the alarm signals from detectors at the keypad initiating the test so that one person can trigger every detector connected to the alarm then return to the keypad to verify operation. -
Page 16: Memory Display Mode
MEMORY DISPLAY MODE VIEW MEMORY MODE The alarm panel has an event memory which stores the most recent events, (up to 255), including all alarm events, all system events such as mains failure etc as well as arming by Area. This event memory is displayed via the standard keypad with the most recent event shown first and subsequent events following in descending order from newest to oldest. -
Page 17: Historical Event Display Chart
LED KEYPAD HISTORICAL EVENT DISPLAY CHART LED KEYPAD HISTORICAL EVENT DISPLAY CHART EVENT DEVICE INDICATOR STATUS ACTIVATION Zones 1-16 LED's 1-16 On Steady BYPASS Zones 1-16 BYPASS On Steady LED's 1-16 On Steady DETECTOR TAMPER Zones 1-8 TROUBLE Flashing (SHORT CIRCUIT) LED's 1-8 On Steady DETECTOR TAMPER... - Page 18 LED KEYPAD HISTORICAL EVENT DISPLAY CHART-Continued EVENT DEVICE INDICATOR STATUS RF FAILURE No RF Activity TROUBLE Flashing AUX (0) Flashing ARM DELINQUENCY ALARM Areas A or B not armed within TROUBLE Flashing “X” days CONTROL Flashing DURESS ALARM Duress Alarm TROUBLE Flashing (at Keypad #)
-
Page 19: Programming Summary Guide
PROGRAMMING SUMMARY GUIDE The program addresses available to the owner in Client Program Mode are listed below. “P” represents the <PROGRAM> button and “E” represents the <ENTER> button. P1E 1-100E (User Codes 1-100) P18E 21-100E (learn radio user 21-100) P19E 21-100E (Delete radio user 21-100) P20E 0E (Find a radio user location) P21E 1-100E (learn access tag/card user 1-100) P22E 1-100E (Delete access tag/card user 1-100) -
Page 20: Owners Details
OWNERS DETAILS NAME: ADDRESS: TELEPHONE NUMBER: INSTALLERS NAME: INSTALLERS CONTACT PH #: ACCESS CODES USER NAMES: Code 1 Code 2 Code 3 Code 4 Code 5 Code 6 Code 7 Code 8 Code 9 Code 10 Code 11 Code 12 Code 13 Code 14 Code 15... -
Page 21: Zone Descriptions
Code 64 Code 65 Code 66 Code 67 Code 68 Code 69 Code 70 Code 71 Code 72 Code 73 Code 74 Code 75 Code 76 Code 77 Code 78 Code 79 Code 80 Code 81 Code 82 Code 83 Code 84 Code 85 Code 86... -
Page 22: Keypad Layout & Indications
KEYPAD LAYOUT & INDICATIONS S series’ ‘ LED KEYPAD READY PROGRAM CONTROL BYPASS AC FAIL MEMORY BATTERY LOW LINE TROUBLE ‘S series’ LED LEYPAD INDICATIONS MEMORY BYPASS STAY CONTROL ENTER PROGRAM ‘S series’ LED & LCD LEYPAD INDICATIONS... -
Page 23: Telecom Notification
TELECOM NOTIFICATIONS The grant of a Telepermit for any item of terminal equipment indicates only that Telecom has accepted that the item complies with minimum conditions for connection to its network. It indicates no endorsement of the product by Telecom, nor does it provide any sort of warranty. Above all, it provides no assurance that any item will work correctly in all respects with another item of Telepermitted equipment of a different make or model, nor does it imply that any product is compatible with all of Telecom’s network services. -
Page 24: Installer Notes
INSTALLER NOTES Installer Notes: Panel Software Version:………………………………... Panel Location:………………………………... Keypad Type (LED/LCD/PROX READER): 1:………………………………... 2:………………………………... 3:………………………………... 4:………………………………... 5:………………………………... 6:………………………………... 7:………………………………... 8:………………………………... Radio Board Fitted: YES/NO Voice Board Fitted: YES/NO MIC Board Fitted: YES/NO Please contact your alarm installer if you require further information.
