  • Page 1 E E a a t t o o n n 9 9 3 3 T T Eaton 93T 15-80 kVA User’s and Installation Guide...
  • Page 2 (even extracts) without the written approval of Eaton Corporation. Every care has been taken to ensure the accuracy of the information contained in this manual, but no liability can be accepted for any errors or omission. The right to make design modifications is reserved.

  • Page 3: Table Of Contents

    Introduction to Eaton UPS........
  • Page 4 6.4 Control the UPS system ............81 EATON 93T USER’S AND INSTALLATION GUIDE...
  • Page 5 Index ............. 117 EATON 93T USER’S AND INSTALLATION GUIDE...

  • Page 6: How To Read This Manual

    These symbols indicate a hazardous situation or action. Symbols are used to warn of situations, which can cause environmental damage and personal injury. General warning sign Explosion and fire hazard Battery hazard EATON 93T USER’S AND INSTALLATION GUIDE 614-40270 - December 2023 www.eaton.eu...
  • Page 7 These symbols are used in warnings and notifications to indicate an action that must be taken. The mandatory action symbols are shown below. Wear eye protection General symbol for mandatory action EATON 93T USER’S AND INSTALLATION GUIDE 614-40270 - December 2023 www.eaton.eu...
  • Page 8 1 1 . . 4 4 G G l l o o s s s s a a r r y y The following acronyms are used in Eaton documentation to refer to Eaton UPS products or their parts. Table 1. Glossary of acronyms...
  • Page 9 Terminal Block Uninterruptible Power Module Uninterruptible Power System UPS system The entire power protection system: the UPS cabinet, the battery cabinet, and the options or accessories installed. VRLA Valve-regulated Lead-acid EATON 93T USER’S AND INSTALLATION GUIDE 614-40270 - December 2023 www.eaton.eu...

  • Page 10: Safety

    Keep this manual for future reference. These instructions are also available for download at www.eaton.eu/ DANGER Operations inside the UPS must be done by an authorized Eaton Customer Service Engineer or by other qualified service personnel authorized by Eaton. There are no user-serviceable parts inside the UPS.
  • Page 11 AC supply is not connected to the UPS. Read the shutdown instructions carefully. IMPORTANT: The battery may consist of multiple parallel strings. Make sure that you disconnect all strings before installation. 1 1 1 1 EATON 93T USER’S AND INSTALLATION GUIDE 614-40270 - December 2023 www.eaton.eu...
  • Page 12 R R e e c c y y c c l l i i n n g g t t h h e e u u s s e e d d U U P P S S o o r r b b a a t t t t e e r r i i e e s s Remove the battery bank before you discard the UPS or its battery cabinet. Obey the local requirements regarding battery recycling or disposal. 1 1 2 2 EATON 93T USER’S AND INSTALLATION GUIDE 614-40270 - December 2023 www.eaton.eu...

  • Page 13: Certification

    C C e e r r t t i i f f i i c c a a t t i i o o n n This product has received the EMC Directive 2014/30/EU certification. 1 1 3 3 EATON 93T USER’S AND INSTALLATION GUIDE 614-40270 - December 2023...
  • Page 14 Declarations of conformity with UPS harmonized standards and directives EN 62040-1 (Safety) and 62040-2 (EMC) are available at or by contacting your nearest Eaton office or http://powerquality.eaton.com authorized partner. 2 2 . . 4 4 U U s s e e r r p p r r e e c c a a u u t t i i o o n n s s The only permitted user operations are: •...

  • Page 15: Environment

    • a question about any of the information in this manual • a question that this manual does not answer 1 1 5 5 EATON 93T USER’S AND INSTALLATION GUIDE 614-40270 - December 2023 www.eaton.eu...

  • Page 16: Introduction To Eaton Ups

    The Eaton 93T 15-80 kVA UPS is applicable to small, medium, and large data centers. It is expandable within 15 kVA and 320 kVA. It is a custom power system solution characterized by industry-leading efficiency, usability, and performance.
  • Page 17 Figure 3. 93T UPS (15–30 kVA) 1. Control panel 8. Output switch 2. Terminal block 9. Neutral switch 3. MiniSlot card 10. Grounding screw 4. Battery startup 11. Battery breaker 5. Input switch 12. Battery 6. Bypass switch 13. Terminals for external batteries 7.
  • Page 18 Figure 4. 93T UPS (40 kVA) 1. Control panel 8. Output switch 2. Terminal block 9. Neutral switch 3. MiniSlot card 10. Grounding screw 4. Battery startup 11. Battery breaker 5. Input switch 12. Battery 6. Bypass switch 13. Terminals for external batteries 7.
  • Page 19 Figure 5. 93T UPS (60–80 kVA) 1. Control panel 8. Output switch 2. Terminal block 9. Neutral switch 3. MiniSlot card 10. Grounding screw 4. Battery startup 11. Battery breaker 5. Input switch 12. Battery 6. Bypass switch 13. Terminals for external batteries 7.
  • Page 20 Figure 6. 93T UPS wiring diagram 1. Bypass supply (230 V, 50 Hz, 3 φ, 12. Rectifier 4 wires) 13. Battery relay 2. Single feed only 14. Battery input 3. Main supply (230 V, 50 Hz, 3 φ, 15. Battery breaker 4 wires) 16.

  • Page 21: Ups Operating Modes

    Path of current through the UPS in Online mode shows the path of electrical power through the UPS system when the UPS is operating in Online mode. 2 2 1 1 EATON 93T USER’S AND INSTALLATION GUIDE 614-40270 - December 2023...
  • Page 22 The UPS returns automatically to Online mode when an abnormal condition, such as an extended overload removal, is cleared and the system operation is restored within the specified limits. 2 2 2 2 EATON 93T USER’S AND INSTALLATION GUIDE 614-40270 - December 2023 www.eaton.eu...
  • Page 23 Online mode and continues to supply power to the load through the inverter. If the input AC power fails or exceeds the system specifications, the UPS transfers automatically to Battery mode to supply uninterrupted power to the load. 2 2 3 3 EATON 93T USER’S AND INSTALLATION GUIDE 614-40270 - December 2023 www.eaton.eu...
  • Page 24 When AC power is interrupted, the rectifier cannot convert AC power into DC output to supply the inverter. The input relay K1 is switched off, and the battery supplies UPS output through the inverter. The inverter 2 2 4 4 EATON 93T USER’S AND INSTALLATION GUIDE 614-40270 - December 2023...
  • Page 25 Figure 10. Path of current through the UPS in Bypass mode Bypass input Internal relay contact closed Static switch Internal relay contact open Output Main power flow Inverter Energized Rectifier De-energized 2 2 5 5 EATON 93T USER’S AND INSTALLATION GUIDE 614-40270 - December 2023 www.eaton.eu...

  • Page 26: Battery System

    P P o o w w e e r r w w a a r r e e H H o o t t S S y y n n c c The Eaton Powerware Hot Sync technology is an algorithm that eliminates the single point of failure in a parallel system and therefore enhances system reliability.
  • Page 27 U U s s e e r r i i n n t t e e r r f f a a c c e e The Eaton 93T UPS includes two communication bays for MiniSlot communication cards. MiniSlot cards are quickly installed and hot-pluggable.
  • Page 28 The UPS units can be connected in parallel to create larger systems. A maximum of four UPSs can be connected in parallel. If you want to connect more than four cabinets in parallel, contact Eaton’s solution team for a power distribution design.
  • Page 29 6. Install any accessories or optional parts, if needed. 7. Complete the installation checklist. 8. Have an authorized Eaton Customer Service Engineer do the preliminary operational checks and startup. Startup and operational checks must be done by an authorized Eaton Customer Service Engineer...
  • Page 30 Below 1,000 m (3,300 ft.) If the system is operated at an altitude above 2,000 m (6,600 ft.), contact Eaton’s service team for more information. The operating environment of the UPS must meet the weight and size requirements provided in Table UPS cabinet dimensions and weights to avoid the risk of an undesirable microclimate at the UPS location.
  • Page 31 800 x 1920 x 1100 500 x 1750 x 820 800 x 1920 x 1100 500 x 1750 x 820 Figure 11. UPS cabinet dimensions (15–80 kVA) 3 3 1 1 EATON 93T USER’S AND INSTALLATION GUIDE 614-40270 - December 2023 www.eaton.eu...
  • Page 32 Above the cabinet In front of the cabinet Behind the cabinet If needed, allow more clearance for wiring. Figure 12. 93T UPS cabinet clearances • If the D3 clearance is less than the minimum clearance specified in Table UPS cabinet minimum clearances, contact your local Eaton representative.
  • Page 33 For external wiring, use copper cable rated for 90 ℃ at minimum. For more information, refer to Table Input/output ratings and external cabling recommendations for the 93T UPS 15–80 kVA. Cable sizes are based on using the specified circuit breakers.
  • Page 34 CAUTION The cable sizes shown in Table Input/output ratings and external cabling recommendations for the 93T UPS 15–80 kVA are only recommendations. They are not mandatory. Refer to the regional standards and user’s requirements to determine the actual cable sizes.
  • Page 35 Input/output disconnecting devices must be provided by the user. When connecting external batteries to the Eaton 93T UPS, Eaton recommends that you use the following NZM-series molded case circuit breakers. Table 10. Recommended NZM-series molded case circuit breakers and their ratings...
  • Page 36 Balance the loads equally between the phases. Refer to Table Input/output ratings and external cabling recommendations for the 93T UPS 15–80 kVA. Source protection for the AC input to bypass must suit the characteristics of the load and take into account effects such as inrush or starting current.
  • Page 37 Sliding the UPS cabinet from the pallet requires a minimum of two people. NOTE: To unload the cabinet from the pallet, complete the following steps. 3 3 7 7 EATON 93T USER’S AND INSTALLATION GUIDE 614-40270 - December 2023 www.eaton.eu...
  • Page 38 NOTE: Do not discard the ramp that is attached to the upper carton. The ramp is used for moving the cabinet off of the pallet. 3 3 8 8 EATON 93T USER’S AND INSTALLATION GUIDE 614-40270 - December 2023 www.eaton.eu...
  • Page 39 4. Attach the ramp to the pallet. Align the ramp with the two pegs located on the front side of the pallet. Make sure that the ramp is locked in position. 3 3 9 9 EATON 93T USER’S AND INSTALLATION GUIDE 614-40270 - December 2023...
  • Page 40 7. Slowly slide the cabinet onto the ground along the ramp. 8. Move the cabinet to the installation site by using the casters on the bottom. 4 4 0 0 EATON 93T USER’S AND INSTALLATION GUIDE 614-40270 - December 2023...
  • Page 41 NOTE: During the installation waiting period, protect the unpacked cabinet from humidity, dust, and other General contaminants. Failure to properly store or protect the UPS will cause the warranty terms specified in 10.1 information about warranty become void. 4 4 1 1 EATON 93T USER’S AND INSTALLATION GUIDE 614-40270 - December 2023 www.eaton.eu...
  • Page 42 UPS to the local power source. The installation inspection and initial startup of the UPS must be carried out by an authorized Eaton Customer Service Engineer or by other qualified service personnel authorized by Eaton. The installation of the battery cabinets can be performed by qualified service personnel of the equipment manufacturer or representative.
  • Page 43 Figure 15. Gland plates, 60–80 kVA UPS 1. Remove the side panel of the cabinet to get access to the connectors. 4 4 3 3 EATON 93T USER’S AND INSTALLATION GUIDE 614-40270 - December 2023 www.eaton.eu...
  • Page 44 Before you drill the holes, make sure that you removed the gland plates from the cabinet. This is to prevent metal shavings or chips from entering into electronics and causing damage to the UPS. 4 4 4 4 EATON 93T USER’S AND INSTALLATION GUIDE 614-40270 - December 2023 www.eaton.eu...
  • Page 45 WARNING Route the wires through the sides of the cabinet to prevent them from blocking the hot ventilation area in the rear of the cabinet. 4 4 5 5 EATON 93T USER’S AND INSTALLATION GUIDE 614-40270 - December 2023 www.eaton.eu...
  • Page 46 12. Neutral 5. L2 (bypass) 13. Battery + 6. L3 (bypass) 14. Battery neutral 7. L1 (output) 15. Battery - 8. L2 (output) 16. Grounding screw 4 4 6 6 EATON 93T USER’S AND INSTALLATION GUIDE 614-40270 - December 2023 www.eaton.eu...
  • Page 47 12. Neutral 5. L2 (bypass) 13. Battery + 6. L3 (bypass) 14. Battery neutral 7. L1 (output) 15. Battery - 8. L2 (output) 16. Grounding screw 4 4 7 7 EATON 93T USER’S AND INSTALLATION GUIDE 614-40270 - December 2023 www.eaton.eu...
  • Page 48 In order to avoid damages to the equipment or injuries to personnel, only commissioning personnel are allowed to perform the connection of these batteries. 4 4 8 8 EATON 93T USER’S AND INSTALLATION GUIDE 614-40270 - December 2023 www.eaton.eu...
  • Page 49 The external battery breakers can be tripped (switched off) by energizing its shunt trip coil. The shunt trip coils are energized (controlled) through connector X8. The status signal of the external battery breaker is also connected to connector X8. Status contacts of the Eaton battery breakers are open if the breaker itself is open.
  • Page 50 S S u u p p p p o o r r t t e e d d b b a a t t t t e e r r y y c c o o n n f f i i g g u u r r a a t t i i o o n n s s In case of a parallel use of the 93T UPS, both common battery and separate battery are supported for the cabinets.
  • Page 51 10. CAN-L parallel communication 4. NO_EPO_POWER 11. Pull-chain -, parallel back control signal 5. EPO_IN 12. Pull-chain +, parallel back control 6. EPO_GND signal 7. NC_EPO_POWER 5 5 1 1 EATON 93T USER’S AND INSTALLATION GUIDE 614-40270 - December 2023 www.eaton.eu...
  • Page 52 Terminal CN12 can be used to connect external alarm signals, such as smoke alarm signals and overheat alarm signals. Use twisted-pair cables to connect the alarm device to its related UPS terminal. For external alarm signal configurations, consult your local Eaton representative. Figure 26. CN12 terminal layout 1. CI_ALM1 5.
  • Page 53 M M i i n n i i S S l l o o t t c c a a r r d d s s The Eaton 93T UPS has two MiniSlot communication bays. The UPS is compatible with the following...
  • Page 54 Warning limits for temperature and humidity can be configured in the network card and monitored in a real-time manner with Eaton’s IPM and IPP software. Temperature compensation for lead-acid battery can be achieved as well.
  • Page 55 P P a a r r a a l l l l e e l l U U P P S S i i n n s s t t a a l l l l a a t t i i o o n n The outputs of multiple 93T UPS systems can be connected in parallel. The outputs are paralleled to increase the load capacity of the power system and for redundancy.
  • Page 56 B B a a t t t t e e r r y y c c o o n n n n e e c c t t i i o o n n In case of a parallel use of the Eaton 93T UPS 15-80 kVA, both common battery and separate battery configurations are supported for the cabinets.
  • Page 57 In the 93T UPS (15–80 kVA), the ECAN, Bypass Pull-Chain, and the external parallel control signal are connected to the external parallel ports. For the location of the ports, refer to Figure Communication interfaces.
  • Page 58 Figure 33. Simplified CAN and Pull-Chain wiring for parallel UPS system Pin 9 Terminating resistance 120 Ω Pin 10 UPS 1 Pin 11 UPS 2 Pin 12 UPS 3 Pin 13 UPS 4 Pin 14 5 5 8 8 EATON 93T USER’S AND INSTALLATION GUIDE 614-40270 - December 2023 www.eaton.eu...
  • Page 59 Accessories are correctly installed and their wiring is terminated inside the UPS cabinet (OPTIONAL). The gaps between the cables and the cabinet are filled with fireproof mud. 5 5 9 9 EATON 93T USER’S AND INSTALLATION GUIDE 614-40270 - December 2023 www.eaton.eu...
  • Page 60 UPS equipment. Start-up and operational checks are performed by an authorized Eaton Customer Service Engineer. 5 5 . . 6 6 . . 2 2 P P a a r r a a l l l l e e l l U U P P S S s s y y s s t t e e m m Action Each cabinet in the UPS system is placed in its installation location.
  • Page 61 Before UPS startup, make sure that all installation work has been completed, and that the initial startup has been performed by qualified service personnel authorized by Eaton. Before the initial startup, examine all electrical connections to make sure that the system has been successfully installed and correct operation is possible.
  • Page 62 UPS system operates in a normal operating mode, only the green “Normal” indicator light is on. If any other indicator lights are on, there is an active alarm or event in the UPS system. In case of an active 6 6 2 2 EATON 93T USER’S AND INSTALLATION GUIDE 614-40270 - December 2023...
  • Page 63 The touch screen on the control panel provides an operating interface for the UPS system. Figure 35. Home page The UPS status bar displays the model of the Eaton equipment, current date, time, and active log information. The energy flow diagram displays information about the energy flow status of the UPS operation.
  • Page 64 Control Access various system control functions. Statistics Access various operating values of the system. Only service personnel authorized by Eaton can change these values. View and clear system events. Info View detailed information on the UPS and the HMI. Setting Access various screen control functions for system operation.
  • Page 65 Figure 37. Input page Figure 38. Output page 6 6 5 5 EATON 93T USER’S AND INSTALLATION GUIDE 614-40270 - December 2023 www.eaton.eu...
  • Page 66 1. Select Control on the Menu page. 2. Enter the initial control password 11111111 and select OK. 3. When the password is verified, select Next. 6 6 6 6 EATON 93T USER’S AND INSTALLATION GUIDE 614-40270 - December 2023 www.eaton.eu...
  • Page 67 1. Select Go To Bypass to access the bypass page. 2. Select Go to Bypass. 3. Select OK to transfer to Bypass mode. These instructions apply to the other functions, as well. 6 6 7 7 EATON 93T USER’S AND INSTALLATION GUIDE 614-40270 - December 2023 www.eaton.eu...
  • Page 68 On the UPM page you can view the UPS status, the battery status, and the UPM status. Tap on the > icon to enter the UPM shutdown interface. A gray icon indicates that the function is unavailable. To shut down 6 6 8 8 EATON 93T USER’S AND INSTALLATION GUIDE 614-40270 - December 2023...
  • Page 69 View all system events. You can view a maximum of 1,024 items on 205 pages. Clear Alarms Clear all active system events displayed on the Active Log page. 6 6 9 9 EATON 93T USER’S AND INSTALLATION GUIDE 614-40270 - December 2023 www.eaton.eu...
  • Page 70 On the Info page you can view the UPS name, UPS serial number, UPM version, and HMI version, among other things. To access the Info page, select Info on the Menu page. 7 7 0 0 EATON 93T USER’S AND INSTALLATION GUIDE 614-40270 - December 2023 www.eaton.eu...
  • Page 71 On the Setting page you can change the display language, time, display brightness, output voltage, and output frequency. You can also change the Control and Setting page passwords. For more information, refer to Table Setting page functions. 7 7 1 1 EATON 93T USER’S AND INSTALLATION GUIDE 614-40270 - December 2023 www.eaton.eu...
  • Page 72 The initial password 01010101 can be used to access the Setting page. password Also users can access the Setting and Control pages with the initial passwords shown in Table NOTE: Control and Setting page passwords. 7 7 2 2 EATON 93T USER’S AND INSTALLATION GUIDE 614-40270 - December 2023 www.eaton.eu...
  • Page 73 Save. To return to the General page, select Cancel. This method can be used to change other parameters, as well. Figure 51. General page 7 7 3 3 EATON 93T USER’S AND INSTALLATION GUIDE 614-40270 - December 2023 www.eaton.eu...
  • Page 74 Figure 52. Output page Figure 53. Meters page 7 7 4 4 EATON 93T USER’S AND INSTALLATION GUIDE 614-40270 - December 2023 www.eaton.eu...
  • Page 75 A red prompt indicates that the reminder is expired. A gray prompt indicates that the reminder is not expired or that the reminder is not enabled. 7 7 5 5 EATON 93T USER’S AND INSTALLATION GUIDE 614-40270 - December 2023...
  • Page 76 Figure 55. Service reminders To create a new service reminder, go to Setting→General and select Service Reminder. Figure 56. Location of the service reminder function 7 7 6 6 EATON 93T USER’S AND INSTALLATION GUIDE 614-40270 - December 2023 www.eaton.eu...
  • Page 77 When the fan replacement configurations are completed and saved, the reminder date and the enable/disable status are displayed on the interface. Figure 58. Fan Replacement page 7 7 7 7 EATON 93T USER’S AND INSTALLATION GUIDE 614-40270 - December 2023 www.eaton.eu...
  • Page 78 UPS in the system. 6. Select Control on the menu, and enter the password to access the control page. 7. Select System on the control page. 7 7 8 8 EATON 93T USER’S AND INSTALLATION GUIDE 614-40270 - December 2023 www.eaton.eu...
  • Page 79 2. Select System on the control page to access the system page. 3. Tap on the Enable ESS icon on the system page, and select OK to confirm. 7 7 9 9 EATON 93T USER’S AND INSTALLATION GUIDE 614-40270 - December 2023...
  • Page 80 8. Turn off the UPS input and bypass distribution switch. 9. If any external battery cabinet is installed, turn off all battery switches, including the neutral battery wire switch. 8 8 0 0 EATON 93T USER’S AND INSTALLATION GUIDE 614-40270 - December 2023 www.eaton.eu...
  • Page 81 1. Tap on the Control icon on the menu page to access the system control page. 2. Tap on the UPS Control icon on the system control page. 3. Select Shutdown on the UPS control page. 8 8 1 1 EATON 93T USER’S AND INSTALLATION GUIDE 614-40270 - December 2023 www.eaton.eu...
  • Page 82 When the REPO push-button is activated, the UPS output is cut off immediately. Use this feature only in case of emergency. The following instructions are for the REPO push-button supplied by Eaton. If you are using a NOTE: customer-supplied REPO push-button, it may not activate in the same way. For operating instructions, refer to the documentation provided with the push button.
  • Page 83 1. Maintenance bypass 5. Rectifier input switch 2. Maintenance bypass switch (MBS) 6. Rectifier input 3. Output 7. Static bypass input 4. Output switch 8. Bypass switch 8 8 3 3 EATON 93T USER’S AND INSTALLATION GUIDE 614-40270 - December 2023 www.eaton.eu...
  • Page 84 Refer to Section Transfer from Bypass mode to Online mode. 6.3.5 Figure 62. Switch status in Online mode 1. Maintenance bypass 2. Maintenance bypass switch (MBS) 8 8 4 4 EATON 93T USER’S AND INSTALLATION GUIDE 614-40270 - December 2023 www.eaton.eu...
  • Page 85 3. Output 6. Rectifier input 4. Output switch 7. Static bypass input 5. Rectifier input switch 8. Bypass switch 8 8 5 5 EATON 93T USER’S AND INSTALLATION GUIDE 614-40270 - December 2023 www.eaton.eu...
  • Page 86 UPS system. WARNING All service and maintenance work must be done only by service personnel qualified and authorized by Eaton. CAUTION A warning label, shown in Figure Warning label, must be installed at the UPS...
  • Page 87 It is recommended that the service and maintenance work is performed by qualified service personnel authorized by Eaton. 7 7 . . 3 3 . . 1 1 D D a a i i l l y y m m a a i i n n t t e e n n a a n n c c e e Do the following maintenance procedures daily.
  • Page 88 4. Make sure that the UPS is in Online mode. The UPS in in Online mode when the Online mode status indicator light is on. If an alarm indicator light is on or the Online mode status indicator is not on, contact your local Eaton service representative. 7 7 . . 3 3 . . 2 2...
  • Page 89 To replace the filters: a. Remove the fastening screws from the UPS front panel. b. Remove the front panel. c. Remove the filter from the front panel. 8 8 9 9 EATON 93T USER’S AND INSTALLATION GUIDE 614-40270 - December 2023 www.eaton.eu...
  • Page 90 To install the battery, refer to the battery manufacturer’s instructions. Recycle used batteries and UPSs. For proper disposal, contact your local collecting, recycling, reuse, or hazardous waste center and obey the local legislation. 9 9 0 0 EATON 93T USER’S AND INSTALLATION GUIDE 614-40270 - December 2023 www.eaton.eu...
  • Page 91 M M a a i i n n t t e e n n a a n n c c e e t t r r a a i i n n i i n n g g For more information about training and other services, contact your Eaton representative.
  • Page 92 A A b b o o u u t t t t r r o o u u b b l l e e s s h h o o o o t t i i n n g g If the UPS is not operating correctly, read the fault description form, contact your local Eaton representative, and provide the following information: 1.
  • Page 93 ESS Not Available Bypass quality is not good Contact your local service or the charging current is representative. greater than the setup limit. 9 9 3 3 EATON 93T USER’S AND INSTALLATION GUIDE 614-40270 - December 2023 www.eaton.eu...
  • Page 94 M M o o d d e e l l s s The frequency range of 40–72 Hz is optional for the UPS systems with different rated output powers. Table 19. 93T UPS models with rated capacity and frequency range 93T UPS model...
  • Page 95 2006/66/EC Packing 2005/20/EC 9 9 . . 4 4 U U P P S S i i n n p p u u t t Table 21. 93T UPS input specifications Rated input voltage 220/380 V 230/400 V 240/415 V Voltage range (rectifier input) 190/330–276/478 VAC (-15 %, +20 %), 100 % load...
  • Page 96 9 9 . . 5 5 U U P P S S o o u u t t p p u u t t Table 22. 93T UPS output specifications Output phases 3 phases + neutral Rated output voltage 220/380 V...
  • Page 97 (1.8 °F) between the dry bulb and the wet bulb of the hygroscope to avoid condensation. Acoustic noise at 1 meter 15–20 kVA UPS: ≤ 55 dB 9 9 7 7 EATON 93T USER’S AND INSTALLATION GUIDE 614-40270 - December 2023 www.eaton.eu...
  • Page 98 < 500 < 2 Table 26. Environmental requirements for transportation and storage within one year* Storage site Indoors Dust Good Storage temperature < 40 ℃ 9 9 8 8 EATON 93T USER’S AND INSTALLATION GUIDE 614-40270 - December 2023 www.eaton.eu...
  • Page 99 If the actual storage environment of the unit does not meet the environmental requirements presented above, re-evaluate the storage time according to the actual storage environment. 9 9 9 9 EATON 93T USER’S AND INSTALLATION GUIDE 614-40270 - December 2023...
  • Page 100 Eaton Field Service Engineer or by other qualified service personnel authorized by Eaton. Service and maintenance of the UPS shall also be performed only by an authorized Eaton Field Service Engineer or by other qualified service personnel authorized by Eaton. Otherwise the warranty will be voided.
  • Page 101 Contracting Entity (as defined below). For the purposes of this Agreement, any reference to “Eaton” shall include the Contracting Entity, its holding company, its affiliates and subsidiaries. This Agreement, and any other terms or conditions notified to you, governs your access to and use of 93T 15-80 kW (the “Product Software”).
  • Page 102 Product Software solely for your own internal business purposes; “Eaton Hardware” means the Eaton product provided by Eaton to you, which may include Product Software within it; “Eaton Open Source has the meaning as defined in Clause 10.1;...
  • Page 103 You shall as soon as reasonably practicable notify Eaton in writing by email or by phone to the relevant contact information provided in the “contact us” section below if you become aware of...
  • Page 104 Product Software, in whole or in part, without the prior written consent of Eaton; and (v) engage in any activity that interferes with or disrupts the Product Software (or the servers and networks connected to the Product Software).
  • Page 105 Eaton is not liable to you or to any third party for any update, change, suspension, discontinuance of any feature or component of the Product Software.
  • Page 106 Product Software in any way that is unlawful, fraudulent or deceptive, or has any unlawful, fraudulent or deceptive purpose or effect; (xi) not use the Product Software except in conjunction with the operation of Eaton products to which the Product Software pertains or other products described by Eaton in the Documentation;...
  • Page 107 Eaton’s ability to deliver the Product Software is dependent upon your cooperation, as well as the accuracy and completeness of any information you provide to Eaton. Eaton shall not be liable for any costs, expenses or liabilities resulting from your failure to cooperate or to provide such information;...
  • Page 108 FEES 11.1 Where applicable, Eaton may charge you fees for access to the Product Software. You agree to pay all fees and charges, within the agreed upon billing period, including taxes, incurred through your account at the rates in effect for the billing period in which such fees and charges...
  • Page 109 In no event shall Eaton nor any of its officers or other representatives be liable for any loss or damages arising out of or in connection with your use, inability to use or reliance on any...
  • Page 110 Eaton or its employees or agents to you or to any third party for damages, direct or otherwise, arising out of or in...
  • Page 111 You agree to only use Eaton’s confidential information for the purposes of obtaining the benefit set out in this Agreement and for no other purpose. You agree not to use or disclose Eaton’s confidential information without the prior written consent of Eaton, except to share it with your employees who have a need to know the information and are bound by a duty of confidentiality covering the information that is at least as restrictive as the obligations in this Agreement.
  • Page 112 22.2 Eaton reserves the right, in its sole discretion and without notice to you, to suspend, terminate, modify or delete an account or access to the Product Software or parts thereof, if you are, or Eaton reasonably suspects that you are, failing to comply with any of the provisions of this Agreement or for any actual or suspected illegal or improper use of the Product Software.
  • Page 113 Links and Ads are not under Eaton’s control. Eaton disclaims all liability and responsibility for any Third Party Links and Ads and you acknowledge and agree that Eaton is not responsible or liable for: (a) the availability or accuracy of such Third Party Links and Ads; or (b) the contents, products or services on or available from such Third Party Links and Ads.
  • Page 114 Eaton’s failure to enforce a term of this Agreement is not a waiver of its right to do so later. No failure or delay by Eaton or its affiliates to exercise any right or enforce 1 1 1 1 4 4 EATON 93T USER’S AND INSTALLATION GUIDE...
  • Page 115 Software, Documentation or other Materials. In that context, you are responsible for complying with all applicable Export Laws. If Eaton wants to deliver and/or grant access to the Product Software, Documentation, Materials, or parts of any of these directly to you, you will support...
  • Page 116 29.1 This Agreement (and any associated order form or other agreements referenced herein) constitutes the entire and exclusive agreement between you and Eaton with respect to the subject matter of this Agreement, and supersedes and replaces any other prior or contemporaneous agreements, or terms and conditions applicable to the subject matter of this Agreement.
  • Page 117 Control signals overview ......57 UPS input ...........95 External parallel system control wiring...58 UPS output ..........96 Power wiring overview .........56 Troubleshooting Introduction to Eaton UPS About troubleshooting ........92 About the Eaton UPS........16 Alarms ............92 Basic system configurations ......28 Looking inside the UPS system ....16 UPS features ..........26...
  • Page 118 Service reminder .........75 Setting page..........71 Status indicator lights........62 System alarms ..........62 System control ..........66 User menu ..........63 Using the touch screen ........63 Warranty ............100 1 1 1 1 8 8 EATON 93T USER’S AND INSTALLATION GUIDE 614-40270 - December 2023 www.eaton.eu...
  • Page 119 Eaton Electric Oy Riistakuja 1 FI-01740 Vantaa, Finland www.eaton.eu Copyright © 2023 Eaton Corporation plc. All rights reserved. Unauthorized copying and lending are prohibited.
